Tuning - F5; Moving The Label - F6; Using The Control Software - Minicom Smart CAT5 Switch 16 IP Operating Manual

81. Tuning – F5
You can tune the image of any computer screen from the Select Computer
window.
To adjust the screen image:
1. Navigate to the computer you wish to adjust.
2. Press F5. The screen image of the selected computer appears, together with the
Image Tuning label.
3. Adjust the image by using the Right and Left Arrow keys.
4. When the image is satisfactory, press Esc.
Note! Picture quality is relative to distance. The further away a remote computer
is from the Smart 16 IP, the lower the image quality, and the more tuning needed.
So place the higher resolution computers closer to the Switch.
82. Moving the label – F6
Position the Confirmation label anywhere on the screen.
To position the label from the Main window:
1. Navigate to the desired computer using the Up and Down arrow keys.
2. Press F6. The selected screen image and Identification label will appear.
3. Use the arrow keys to move the label to the desired position.
4. Press Esc to save and exit.
83.

Using the Control software

As an alternative to the OSD operate the system with the Control software located
on the Marketing & Documentation CD. With the OSD you operate the system
and view the computer screens on the same monitor. The Control software
requires 2 monitors: 1 for the software and 1 to view the computer screens.
With the Control software you can:
•
View computers
•
Edit OSD settings
•
Save configurations for future use
•
Read configurations from and write configurations to the Smart 16 IP
Switch
