Looking Up Archives; Sorting Archives - Polycom RSS 2000 User Manual

server name, video start time, duration, video recording rate, video protocol
used, whether or not H.239 was used, and the file size.
Table 2-12
Item
Video Name
Server
Start Date/Time
Duration
Rate
Video
H.239
File Size

Looking Up Archives

In the archive table, the user can look up archives by their archive names, as
shown below:
Figure 2-47
Enter the keyword for the archive's name in the inquiry input box, and then
click the apply button to inquire. After successfully looking it up, the video
table shows all archives that contain the keyword entered.
The keyword entered in the inquiry input box is case sensitive.

Sorting Archives

Besides looking up archives by their archive names, the RSS 2000 also
provides the function of sorting by archive properties. The video properties
that the files can be ordered by include: video name, server, start date/time,
duration, rate, video, H.239, and size.
Archive Properties Details
Details
The default name for videos generated by recording follows
the naming rule of "endpoint H.323 name (recording room
name) + recording time". Video names can be edited after
being generated by recording.
Shows the H.323 name of the RSS 2000 device the archive is
saved on.
The start time is the RSS 2000 device's time when recording
starts.
Shows the duration of the archive.
The rate of the connection between the endpoint recording the
video and the RSS 2000, expressed in Kbps.
The video protocol used by the connection during recording of
the video.
Whether or not H.239 was enabled during recording of the
video.
The size of this archive, expressed in KB.
Enquiring Archives
Polycom RSS 2000 User Guide
2-41
