Polycom RSS 2000 User Manual page 18

Chapter 2 - Web User Interface (UI)
Table 2-3
Item
Serial number
Current running version
Activation status
Downloaded version
Minimum version
requirement
Activation of a newly-purchased RSS 2000
After the user purchase a new RSS 2000 server, he must obtain the device's
Key Code and Upgrade Key Code from the Polycom Resource Center before
the user can activate the device. Only an activated RSS 2000 can perform
normal recording. The following are the specific activation steps:
Step 1 – Get a Key Code for the Basic, Multicast or Clustering Functions
Activation
1
2
3
2-6
Details of Activation Configuration Items
Details
Displays the RSS 2000's product serial number.
Displays the system software version currently installed on
the RSS 2000.
Displays whether the RSS 2000 has been activated. Will
show "Not activated" when the device has not been
activated, and will otherwise show "Activated".
Displays the version of system software that has been
uploaded to the RSS but not yet used in upgrading the
system software. No message will be displayed here after
successfully upgrading.
Displays the minimum software version required by the
device when downloading software for upgrading.
Upgrading cannot be performed if the current version on
the device is lower than the minimum required version. No
message will be displayed here after successfully
upgrading.
Click on the "Polycom Resource Center" button to enter the Polycom
Resource Center login page.
Enter your Email address and password in the login box, and then click
on Sign In. If you are a new user, click on the "Register for An Account"
link to register and obtain a login password.
After successfully registering, click on "Service & Support" in navigation
bar on top of the screen, then click the "Product Activation" in the
navigation bar on the left side of the entered page, as shown in below
figure.
