Polycom RSS 2000 User Manual page 37

Figure 2-31 Add Endpoint
Table 2-8 Details of Endpoint Configuration Items
Item
Name
IP
E.164(optional)
H.323 ID (optional)
Enable Immediate
Recording
•
When adding an endpoint name, duplication is not permitted. Name and IP
address are required fields.
•
When adding an endpoint, the content set for the IP address, the E.164 number,
and the H.323 ID will be authenticated in accordance with the settings on the
recording rights and the viewing rights.
•
The maximum number of endpoints that can be added is 200.
Edit Endpoint Properties
For existing endpoints, the user can click the endpoint properties icon
to edit their properties. Endpoint names cannot be edited.
Delete Endpoint
To delete an endpoint on the Endpoints page, after selecting this endpoint's
corresponding check box, click the "Delete" button. The user can select one
endpoint or multiple endpoints for deletion. The user can also select all
endpoints for deletion.
Details
Enter the name to identify the endpoint. The user can enter
any combination of letters or numbers, but the length
cannot exceed 32 characters.
Enter the endpoint's IP address.
Enter the endpoint's E.164 number registered to GK.
Enter the endpoint's H.323 ID registered to GK.
Recording will start automatically when the RSS 2000
receives a call from this endpoint's configured IP address.
Use this setting to allow specific endpoints to bypass all
Onscreen menus and begin recording immediately upon
connection to the RSS 2000.
Polycom RSS 2000 User Guide
2-25
