Polycom ™ RSS 2000 V1.0
Getting Started guide
General Safety Precautions
Follow these rules to ensure general safety:
• Keep the area around the Polycom RSS 2000 unit clean, free of clutter
and well ventilated.
• Decide on a suitable location for the equipment rack that will hold
the RSS 2000 unit and is near a grounded power outlet.
• • Use a regulating uninterruptible power supply (UPS) to protect the
RSS 2000 unit from power surges and voltage spikes, and to keep it
operating in case of a power failure.
Hardware Specification
Pentium 4, 2.8Mhz,1.5G RAM,250G Hardisk.
• Form Factor: 1U 19" rack mount
• Height: 1.73" (44 mm)
• Width: 16.83" (430 mm)
• Depth: 15.35" (390 mm)
• Gross Weight: 22.4 lbs (10.2 kg)
• Power Supply: Thermal controlled 220W
ATX AC power supply w/PFC
• AC Voltage: 100 - 240 VAC, 60-50 Hz, 5-3
Amps
XP OS
Preparations
Obtain the following information from your network administrator:
• RSS 2000 unit, Subnet Mask and Default Gateway IP addresses
• Gatekeeper IP address, Prefix, and E.164 of the RSS 2000.
DOC2153A
RSS 2000 Getting Started guide + Corrections- V1.0.1.002.doc.1.002
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the RSS 2000 and is the answer not in the manual?

Questions and answers

Related Manuals for Polycom RSS 2000

Summary of Contents for Polycom RSS 2000

  • Page 1 General Safety Precautions Follow these rules to ensure general safety: • Keep the area around the Polycom RSS 2000 unit clean, free of clutter and well ventilated. • Decide on a suitable location for the equipment rack that will hold the RSS 2000 unit and is near a grounded power outlet.

  • Page 2: Unpacking And Installing The Rss 2000

    Unpacking and Installing the RSS 2000 1 Place the RSS 2000 unit on a stable flat surface in the selected location. 2 To connect to the power source, insert the power cable into the Power connector on the rear panel of the MGC+ unit and insert the Power cable into the power source socket.

  • Page 3: Initial Rss 2000 Ip Configuration

    2. Via a RS232 or Telnet Console. 1. Changing the initial IP address via a cross over lan cable 1. Connect a cross over lan cable to LAN1 in the RSS 2000. 2. Set your laptop to the same segment of the RSS a.
  • Page 4 4. Login to the system. User name: Administrator Password: polycom 5. Go to system configuration->IP setting and modify the IP address. Click the save button and than reset the system. DOC2153A RSS 2000 Getting Started guide + Corrections- V1.0.1.002.doc.1.002 Page 4...
  • Page 5 2.Changing the initial IP address via an RS232 Console or Telnet Another option to modify the IP address of the RSS 2000 is using the RS232 console. 1.Connect to the RS232 port – and activate the console (9600, 8bits) Login: polycom (or any administrator password) When login to the console, you will see the current IP address of the system.
  • Page 6 Port Range Manager Trace 30011 Gatekeeper 1719 1720 Endpoint/ Q.931 Socket 1720 H.323 H.245 Socket 1730-1739 Audio / Video / Data 2000-2099 Live Broadcast 1800-1801 Media On Demand Archive 2800-2859 DOC2153A RSS 2000 Getting Started guide + Corrections- V1.0.1.002.doc.1.002 Page 6...
  • Page 7 RSS cannot apply the request. Since all audio/video data are from the media file. System Reset Hard reset (power off and on) is not recommended. Reset should be done via the Web UI or Console service whenever possible. DOC2153A RSS 2000 Getting Started guide + Corrections- V1.0.1.002.doc.1.002 Page 7...
  • Page 8 HDX Release - 1.0.0-259). H.264 HD Limitation H.264 maximum rate is set to 1920K to allow HD connection DOC2153A RSS 2000 Getting Started guide + Corrections- V1.0.1.002.doc.1.002 Page 8...
  • Page 9 (in a ratio of 1 to 6 (for each minute recording the archive will be ready to view in 6 minutes) process after recording is stopped Live streaming is not available for HD calls DOC2153A RSS 2000 Getting Started guide + Corrections- V1.0.1.002.doc.1.002 Page 9...
  • Page 10 Security Update for Windows XP (KB905749) KB905915 Security Update for Windows XP (KB905915) KB908519 Security Update for Windows XP (KB908519) KB908531 Update for Windows XP (KB908531) KB910437 Update for Windows XP (KB910437) DOC2153A RSS 2000 Getting Started guide + Corrections- V1.0.1.002.doc.1.002 Page 10...
  • Page 11 Security Update for Windows XP (KB922819) KB923191 Security Update for Windows XP (KB923191) KB923414 Security Update for Windows XP (KB923414) KB924191 Security Update for Windows XP (KB924191) KB924496 Security Update for Windows XP (KB924496) DOC2153A RSS 2000 Getting Started guide + Corrections- V1.0.1.002.doc.1.002 Page 11...
