Chapter 1-

RSS 2000 Installation and Preliminary Configuration

Unpacking and Installing the RSS 2000

Figure 1-2

The system is shipped with a default IP address:

IP Address: 192.168.1.254

Subnet Mask: 255.255.255.0

Gateway: 192.168.1.1

There are two ways to change the initial IP address of the system:

•

Changing the initial IP address via a cross over LAN cable

1-2

Place the RSS 2000 unit on a stable flat surface in the selected location.

To connect to the power source, insert the power cable into the Power

connector on the rear panel of the RSS 2000 unit and insert the Power

cable into the power source socket.

Connect the LAN cable to LAN 1 port on the rear panel of the RSS 2000

unit.

Turn on power switch.

Cables Connection

Via a cross over LAN cable

Via a RS232 or Telnet Console.

Connect a cross over LAN cable to LAN 1 port on the rear panel of the

RSS 2000 unit..

Configure your PC to the same segment of the RSS 2000. For example,

set the IP address as that shown below:
