Odd

2.4.5 STOP BIT

2 stop bits

2.4.6 FLOW CONTROL

By default, there is no flow control in use. Select the flow control (handshake) method.
Options
No
Scanner Ready
Data Ready
Inverted Data Ready
*None
Description
No flow control
The scanner will activate the RTS signal upon powering on. After each good
read, the scanner will then wait for the CTS signal to become active. Data
will not be sent until the CTS signal becomes active.
The RTS signal will be activated after each good read. The scanner will then
wait for the CTS signal to become active. Data will not be sent until the CTS
signal becomes active.
It works the same as the Data Ready flow control, except that the RTS
signal level is inverted.
Chapter 2 Selecting Output Interface
* 1 stop bit
Scanner Ready
Update
65
