XML Interface

XML for the External Server
The Access Gateway sends a string of XML commands according to specifications. HTTP
headers are added to the XML packets that are built, as the billing "mirroring" information is
sent to the external server in HTTP compliant XML format.
added to the HTTP post.
The XML string built from the billing mirror record is in the following format:
Access Gateway to External Server:
<USG RMTLOG_COMMAND="ADD_REC">
<REC_NUM>max 4 characters </REC_NUM>
<USG_ID>max 6 characters </USG_ID>
<PROPERTY_ID>max 64 characters</PROPERTY_ID>
<DATE>max 10 characters </DATE>
<TIME>max 8 characters</TIME>
<ROOM_NUM>max 20 characters</ROOM_NUM>
<AMOUNT>max 10 characters</AMOUNT>
<TRANS_TYPE>max 5 characters </TRANS_TYPE>
</USG>
Format for each field:
REC_NUM:00923 (numbers only, no alpha characters)
Access Gateway_ID:00020b
PROPERTY_ID:Any regular string
DATE:03/30/2001 (mm/dd/yyyy)
TIME:23:41:38 (24 hour format)
ROOM_NUM:Any regular string
AMOUNT:234.34
TRANS_TYPE:CC
RESULT_VALUE:OK or ERROR
IP:Standard IP address format (123.123.123.123)
Quick Reference Guide
Content-length has also been
287
