Nomadix Access Gateways User Manual page 265

A G
CCESS ATEWAY
E
NVIRONMENTAL
Operating temperature: 5°C to 40° C
Storage temperature: 0°C to 70° C
Operating humidity: 20 - 90% RH non-condensing
Storage humidity: 5 - 95% RH
Altitude: Up to 15,000ft
C
OMPLIANCE
UL
UL (US and Canada)
FCC Class A
CE:
EN 55022: 2006 + A1: 2007
EN 55024: 1998 + A1: 2001 + A2: 2003
IEC 61000-4-2: 1995 +A1: 1998 + A2: 2000
IEC 61000-4-3: 2006
IEC 61000-4-4: 2004
IEC 61000-4-5: 2005
IEC 61000-4-6: 2007
IEC 61000-4-8: 1993 : A1: 2000
IEC 61000-4-11: 2004
EN 61000-3-3: 1995 +A1: 2001 +A2: 2005
Low Voltage Directive:
European Council Directive 2006/95/EC
IEC 60950-1: 2005 (2nd Edition)
EN60950-1:2006 + A11: 2009
I
NTERFACES
3 x 10/100 Mbps Ethernet (RJ-45)
1 x DB9 serial (for serial management and PMS interface)
LED I
NDICATORS
ACT/LINK and 10/100 for each Ethernet port
Power
Quick Reference Guide
AG 2300 Specifications
253
