Landing Gear.
C/A glue.
Locker glue.
3) A drop of C/A glue on the wheel collar
screws will help keep them from coming lose
during operation.
Repeat the process for the other wheel.
www.seagullmodels.com
wheel Pant.

INSTALLING THE MAIN LANDING GEAR.

1) The blind nuts for securing the landing
gear are already mounted inside the fuselage.
2) Using the hardware provided, mount the
main landing gear to the fuselage.
4x20 mm.

MOUNTING THE ENGINE.

1) Position the engine with the drive washer
(150mm) forward of the firewall as shown.
145mm.
2) Use a pin drill and 4mm drill bit to drill a
small indentation in the mount for the engine
mounting screw.
4mm.
11
