Engine Mount Installation - Seagull Models SPORT CRUISER Assembly Manual

INSTALL ELEVATOR CONTROL
HORN.
Fiberglass control horn.
Epoxy
Aileron control horn.
INSTALL RUDDER CONTROL HORN.
Repeat steps to install the rudder control horn
as same as steps done for ailerons.
Fiberglass control horn.
www.seagullmodels.com
Epoxy
Epoxy.

ENGINE MOUNT INSTALLATION.

1) Locate the items necessary to install the
engine mount included with your model. .
4x30mm.
2) Use four 4x30mm head bolts and four 4mm
washers to attach the engine mount rails to
the firewall. Tighten the screws . Make sure to
use threadlock on the screws to help prevent
them from vibrating loose.
Thread locker glue.
Rudder control horn.
7
