www.seagullmodels.com
AILERON PUSHROD HORN INSTALLATION
80mm.
M3 clevis.
M3 lock nut.
100mm.
Wing.
M2 lock nut.
Aileron.
9) Set the aileron hatch in place and use a
Phillips screw driver to install it with four wood
screws.
INSTALLING THE FLAP SERVO
Repeat the procedure for the aileron servo.
Wing.
M2 lock nut.
Flap.
Wing
.
Aileron
.
Wing
.
Aileron
.
Repeat the procedure for the other aileron servo.
19
