Summary of Contents for Direct IP Network Camera
-
Page 3: Compliance Notice Of Fcc
Network Camera WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. COMPLIANCE NOTICE OF FCC: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. -
Page 4: Important Safeguards
Operation Manual Important Safeguards 1. Read Instructions 10. Overloading All the safety and operating instructions should be read Do not overload wall outlets and extension cords as this can before the appliance is operated. result in the risk of fire or electric shock. 2. -
Page 5: Table Of Contents
Network Camera Table of Contents Chapter 1 — Introduction ................1 In This Manual ..................1 Features ....................1 Typical Applications ................. 2 With DirectIP NVR ................2 With Non-DirectIP NVR or Without NVR ......... 3 Chapter 2 — Installation................5 Package Contents .................. - Page 6 Operation Manual Alarm Out ..................43 Email ....................44 Remote Callback ................45 Audio Alarm ..................46 FTP Upload ..................47 Record ....................48 Event ...................... 51 Alarm In .................... 51 Motion Detection ................53 Trip-Zone ..................54 Audio Detection ................55 Tampering ..................
-
Page 7: Chapter 1 - Introduction
Network Camera Chapter 1 — Introduction In This Manual This manual is intended for users of the network camera and includes instructions for using and managing the camera on the network. Features This network camera compresses live video and transmits the video over Ethernet connections. -
Page 8: Typical Applications
Operation Manual IP66-level for water resistant protection and dustproof against rain and dust (not supported for the flushed model) NOTES: In this manual, a “remote system” refers to a PC that the remote program (iNEX Basic or WebGuard) is running. ... -
Page 9: With Non-Directip Tm Nvr Or Without Nvr
Network Camera With Non-DirectIP NVR or Without NVR... - Page 10 Operation Manual...
-
Page 11: Chapter 2 - Installation
Network Camera Chapter 2 — Installation Package Contents Network Camera Installation CD (INIT/iNEX Basic software and operation manual) Quick Guide Mount Kits Dimensions Indoor Outdoor Flushed... -
Page 12: Illustrated Parts List
Operation Manual Illustrated Parts List Indoor and Outdoor < Body > < Body – Bottom Side View > ① Lens ② Micro SD Memory Card Slot ③ Dome Cover ④ Waterproof Sealing (black rubber) ⑤ Cable ⑥ Safety Wire Ring ⑦... -
Page 13: Flushed
Network Camera < Outdoor Sun Shield* > ① Outdoor Bracket Setscrew Hole ② Sun Shield Fastening Screw Hole * The outdoor bracket and sun shield are purchased separately. Ask your dealer or distributor about purchasing it. Flushed < Housing >... -
Page 14: Cable
Operation Manual Cable Assembly: See below. Wall/Ceiling Mounting Holes: Allows you to screw the camera to the wall or ceiling. Sun Shield Setscrew Hole, Outdoor Bracket Setscrew Hole: When installing an outdoor camera, it connects the outdoor bracket to the sun shield. ... -
Page 15: Factory Reset
Network Camera − ALI: Connect an alarm-in device. Mechanical or electrical switches can be wired to the IN and GND (Ground) connectors. The voltage range is from 0V to 5V. When the electrical switch is wired, the threshold voltage for NC (Normally Closed) is above 4.3V and for NO (Normally Open) is below 0.3V, and it should be stable at least 0.5 seconds to be detected. -
Page 16: Mounting
Operation Manual Cut off the power from the camera → Remove the dome cover and poke a straightened paperclip into the factory reset switch hole. → Turn on the power while holding the reset switch → Release the switch in about 5 seconds after the power is applied → The camera resets to factory defaults and restarts after completing the factory reset →... - Page 17 Network Camera < Outdoor > 1. Remove the indoor bracket setscrew from the camera body. 2. Screw the sun shield to the camera body by using the sun shield setscrew provided with the camera. In case that a universal nut is attached to a pipe, connect the sun shield and outdoor bracket first, then connect it to the pipe as follows: 3.
- Page 18 Operation Manual < Flushed > The camera is mounted in the housing. 1. Remove the ceiling tile from the ceiling. Draw circle whose diameter is 200 mm on the tile. Cut the circle out of the ceiling tile. 2. Connect the external devices, network and power adapter. 3.
-
Page 19: Chapter 3 - Remote Setup
Network Camera Chapter 3 — Remote Setup Remote Setup allows you to change all settings of a camera. Camera Protocol The camera supports DirectIP and Open protocols. DirectIP Protocol: − It enables connection to the camera without the need to configure network settings of the camera by using with a DirectIP NVR. -
Page 20: Quick Setup
Operation Manual NOTE: You can also change the settings by using remote programs. Clicking a menu on the left side of the Remote Setup screen displays the current settings for that menu on the right side of the screen. Clicking a submenu under each menu allows you to change the settings. -
Page 21: System
Network Camera System You can change a camera’s system information, import or export all settings, and add users or groups. General Language: Choose the language to be used during remote setup. Name: Enter the camera name (up to 31 characters including spaces). -
Page 22: Date/Time
Operation Manual − Export Setup…: Click to save the current camera settings as a .dat file format. A setup screen appears allowing you to name the setup file. NOTES: The Load Default Setup and Import Setup functions are permitted only to the users in the Administrator group. -
Page 23: User/Group
Network Camera User/Group User/Group: Click the buttons to change the settings for a group or a user allowed controlling the camera remotely. − Add Group: Click to add a group. Enter the group name and set authority levels for the group to control the camera remotely. -
Page 24: Network
Operation Manual – Alarm-Out Control: The user can reset the output during an alarm. – System Check: The user can view and check the remote system status. – Search: The user can search video recorded on the SD memory card by using a remote program. -
Page 25: Fen
Network Camera − ADSL: Select when the camera is networked via ADSL. Enter the ID and password for ADSL connection, and click the OK button. A temporary IP address is automatically assigned to the camera. The camera periodically will be issued a new IP address automatically. -
Page 26: Port/Qos
Operation Manual Help Desk: Choosing the OK button registers the camera on the FEN server. Proper FEN settings will display the help desk information of the FEN server. NOTES: The FEN (For Easy Network) function allows the camera to use dynamic IP addresses for remote connection. - Page 27 Network Camera Use, Port: Check the box to enable and enter the port number. Admin, Watch, Record and Search ports are set to use by default and you cannot change it. Checking the WebGuard or RTSP box allows you to connect to the camera by using the WebGuard program or media players, such as VLC Player, supporting RTSP (Real-Time Streaming Protocol) service.
-
Page 28: Bandwidth Control
Operation Manual CAUTIONS: When changing the port settings, you must change the port settings on remote programs too. When using the HTTPS protocol, the ONVIF protocol might not work. Bandwidth Control You can control the network bandwidth by limiting the network bandwidth of the camera depending on the network traffic. -
Page 29: Security
Network Camera Security IP Filtering: Check the box to use the IP filtering function. You can allow or block connections to the camera by designating IP addresses. − Add: Click the button to add IP addresses to the Allow List or Deny List to allow or block connection to the camera. -
Page 30: Ieee 802.1X
Operation Manual IEEE 802.1X Check the IEEE 802.1X box to use the IEEE 802.1X network connection authentication function. Certificates: Uploads a certificate or private key for network connection depending on the authentication type. Entering a private key password might be required depending on the authentication type. -
Page 31: Video
Network Camera Video You can set up camera setting and features for streaming, webcasting, MAT, privacy masking and PTZ. Camera Image Sensor: Click the tab to set up image sensor settings. Mirroring: Check the Horizontal or Vertical box to flip images horizontally or vertically. - Page 32 Operation Manual White Balance: Click the tab to set up white balance settings. Preset: Select the preset white balance value based on the conditions. − Auto: Select to adjust the white balance automatically. The system identifies the light source of where the camera is installed and sets up the proper white balance for the conditions.
- Page 33 Network Camera Exposure: Click the tab to set up exposure settings. AE Target Gain: Set the target gain for the exposure compensation. The camera compensates the exposure automatically based on the selected target gain. The higher the value is, the brighter the images are.
- Page 34 Operation Manual Day & Night: Click the tab to set up day & night settings. B&W Mode: When in the black and white mode, images are displayed in black and white and are clearer in low light conditions. This feature will be disabled if the Day & Night Mode event action is enabled during the Event –...
-
Page 35: Streaming
Network Camera Miscellaneous: Click the tab to set up other settings. Video Output: Select t . The BNC video out may not work depending he video signal for video output on the settings in the Video – Streaming menu. - Page 36 Operation Manual Primary, Secondary, Tertiary, Quaternary: The camera supports multistream video (priority: Primary > Secondary > Tertiary > Quaternary). Set whether to enable or disable the streams. Some of the settings may change depending on the settings of streams of higher priority and the tertiary and quaternary streams may not be available (see the table below).
-
Page 37: Webcasting
Network Camera Checking the On box allows you to set up the streaming area. − Resolution Limit: Displays the available maximum resolution of the streaming area. − Resolution: Sets the streaming area. The streaming area is displayed in red on the... -
Page 38: Mat
Operation Manual The camera can stream live video from the camera to a website. HTML Code: Copy the HTML Code that is displayed on the screen and paste it in your web page code. Stream: Select a stream to use for webcasting. Only the streams in use are available. NOTE: To use the webcasting service, you must check the Allow Anonymous Login option during 3.2 System –... -
Page 39: Privacy Masking
Network Camera NOTE: The MAT (Motion Adaptive Transmission) function allows you to reduce bandwidth overload and to save storage capacity by reducing the frame rate when no motion is detected. The camera considers that no motion is detected when no change is detected between two consecutive images based on the sensitivity setting. -
Page 40: Ptz
Operation Manual − (Select) or (Clear): Click to select or clear a block for privacy masking area. You can select or clear the several blocks of an area using the mouse dragging. − (Direction): Click to move the direction of the camera by panning or tilting the camera. - Page 41 Network Camera Set up the Preset position by using the following buttons. − (Direction): Click to move the direction of the camera by panning or tilting the camera. − Zoom (In/Out): Click to zoom in or out. − Focus (Near/Far): Click to focus on near or far objects.
- Page 42 Operation Manual Scan: Click the tab to set up Scan function. NOTE: The Scan function makes the camera move between two positions. The Scan function to work, two or more Preset positions should be set up. A list of the saved Scan is displayed. The number indicates the Scan number. Clicking the Set up button allows you to set up the Scan function ...
- Page 43 Network Camera − Name: Enter the Scan name. − Start, Stop: Select a Preset position to start or end scanning. − Dwell Time (sec.): Set the dwell time for the camera to stay at the Start and End position of the scan.
- Page 44 Operation Manual Record: Select the desired Pattern number and enter the Pattern name → Click the OK button → The camera starts saving the camera movement from now on. Move the camera by using the direction, zoom or focus buttons → Click the Stop button to stop saving.
- Page 45 Network Camera Tour: Click the tab to set up Tour function. NOTE: The Tour function makes the camera execute several functions in the predefined order. A list of the saved Tour is displayed. The number indicates the Tour number. Clicking the Set up button allows you to set up Tour function ...
- Page 46 Operation Manual − Name: Enter the Tour name. − No.: Displays the order of functions to run. − Function: Select a function to run. − Dwell Time (sec.): Set the dwell time for the function to last. − Speed: Set the Preset movement speed.
-
Page 47: Audio
Network Camera Lens Reset: Click the button to reset the lens setting when video is out of focus by external shocks. The focus will be adjusted. Home Position: Select the default camera position. − Default: Sets the original factory default position as the home position. -
Page 48: Input/Output
Operation Manual Input/Output Audio CODEC: Select an audio codec. Input: Check the box to enable audio in and adjust the volume. Output: Check the box to enable audio out and adjust the volume. NOTE: The camera does not have amplified audio output, so you need to use a speaker with an amplifier. -
Page 49: Alarm Out
Network Camera Alarm Out Check the Alarm Out box to activate alarm out. Dwell Time: Select the alarm-out dwell time. An alarm out is activated for the preset dwell time after detecting an event. Schedule: Set up the period to enable alarm out. An alarm out can be activated only during... -
Page 50: Email
Operation Manual Email Check the Email box to send an email. SMTP Server, Port: Enter the IP address or domain name and port number of the SMTP server attained from your network administrator. You can use the domain name instead of the IP address if you set up the DNS server when setting up the network. -
Page 51: Remote Callback
Network Camera Remote Callback Check the Remote Callback box to send a callback message to remote systems (Not supported for the WebGuard program). IP Address, Port: Enter the IP addresses and port numbers of the remote systems to send a message. -
Page 52: Audio Alarm
Operation Manual Audio Alarm Check the Audio Alarm box to sound by playing back an audio file. List: Displays the audio file to be played back. You can add or delete an audio file (.wav) (16 bits/16 KHz encoded file only) by clicking the Add or Remove button. Selecting an audio file in the list and clicking the Play or Stop button allows you to test the sound by playing back the selected audio file. -
Page 53: Ftp Upload
Network Camera FTP Upload Check the FTP Upload box to upload event detected images in JPEG file format to an ftp server. FTP Server: Click the Add button to register an ftp server. Clicking the Remove button deletes the registered ftp server. When an event is detected, the event detected images will be uploaded in JPEG file format to the ftp server registered as a primary server. -
Page 54: Record
Operation Manual − Upload Frequency: Displays only when the upload type is set to Always. Set up the upload rate, and the preset number of images will be uploaded to the ftp server during the preset time. − Upload 1 image per: Displays only when the upload type is set to Event. Set up the upload rate. - Page 55 Network Camera Check the Record box to enable recording on a micro SD memory card. Ensure that the SD memory card (Class 6 or higher) is inserted properly. Total Capacity: Displays the total capacity of the SD memory card when an SD memory card is inserted properly.
- Page 56 Operation Manual Settings: Click the tab to set up recording settings. Recording Stream: Select a stream to use for recording. − Time-Lapse/Pre-Event, Event: Allows using a different stream depending on the recording mode. Time-Lapse/Pre-Event: Select the stream to use for recording when in the time-lapse recording mode or for pre-event recording when in the event recording mode.
-
Page 57: Event
Network Camera NOTES: Searching and playing back video recorded on the SD memory card is supported by using a remote program. Refer to the User’s Manual for the remote program for details. Searching and playing back video recorded on the SD memory card might not be very smooth when using a remote program while also recording video on the SD memory card. - Page 58 Operation Manual Check the Alarm In box to set up an alarm-in event. When the camera senses an input on the alarm input connector, it considers it as an event. Title: Enter the alarm-in device’s name. Type: Select the alarm-in type. ...
-
Page 59: Motion Detection
Network Camera Motion Detection Check the Motion Detection box to set up a motion detection event. When the camera detects a motion in a configured motion detection zone, it considers the motion as an event. Sensitivity: Set the motion sensitivity for daytime and nighttime independently. The higher the number is, the more sensitive it is. -
Page 60: Trip-Zone
Operation Manual − Send Email: Check the box to send an email. Selecting Image Attachment attaches an event detected image file (.JPG) to the email. − Remote Callback: Check the box and select the remote systems to send a message (Not supported for the WebGuard program). -
Page 61: Audio Detection
Network Camera − Trip Direction: Select the direction of the moving to be considered as an event. Selecting In considers a moving as an event when the moving to the area is detected, and selecting Out when the moving from the area is detected ... - Page 62 Operation Manual Check the Audio Detection box to set up an audio detection event. When the camera detects audio during the preset activation time, it considers it as an event. Sensitivity: Set the audio sensitivity. The higher the number is, the more sensitive it is. ...
-
Page 63: Tampering
Network Camera Tampering Check the Tampering box to set up a tampering detection event. When a radical change is detected in video (for example, the camera is moved, lens is blocked, etc), it considers it as an event. Sensitivity: Set the tampering sensitivity. The higher the number is, the more sensitive it is. -
Page 64: System Event
Operation Manual System Event Check the System Event box to set up a system event. The camera checks and reports the system and alarm-in status and SD memory card on or off. System Alive: Check the box to check the system operation, and select the check interval. −... -
Page 65: Chapter 4 - Webguard
Network Camera Chapter 4 — WebGuard You can monitor live video images from the camera or search recorded image saved in the SD memory card on the web browser by using the WebGuard program. Computer system requirements for using WebGuard are: ®... - Page 66 Operation Manual NOTES: Do NOT close the LOGIN window during the WebGuard operation, otherwise, it will cause a script error when switching between Web monitoring and Web search modes, and you will need to restart the WebGuard program. There might be a problem with the bottom of the WebGuard page being cropped caused by the address or status bars in Microsoft Internet Explorer 7.0.
-
Page 67: Web Monitoring Mode
Network Camera Web Monitoring Mode ① Log Out: Click to log out of the WebGuard program. ② Version: Position the mouse pointer on the logo to see the WebGuard program version. ③ Date/Time: It displays the current date and time. - Page 68 Operation Manual ⑮ Event Status Window: The event status window at the bottom displays a list of events that were detected in the camera. Alarm In On/Off Motion Detection Trip-Zone Tampering Audio Detection Screen: Clicking the right mouse button on the screen displays the screen popup menu. −...
-
Page 69: Web Search Mode
Network Camera Web Search Mode ① Log Out: Click to log out of the WebGuard program. ② Version: Position the mouse pointer on the logo to see the WebGuard program version. ③ Date/Time: It displays the date and time of the recorded image. - Page 70 Operation Manual video are highlighted in light blue. Selecting a data containing recorded video loads the earliest recording from that date. Selected date is highlighted in orange. Time-Lapse Search: Click to enter the time-lapse search mode whichIt allows you to search for recorded data by time and then play back images found within the time parameters.
-
Page 71: Appendix
Network Camera Appendix Connector Pin Outs Audio Input Common GND (Chassis Ground) Alarm Out (Normally Open) Audio Out Alarm Input GND (Chassis Ground) GND (Chassis Ground) Video Output Troubleshooting Problem Possible Solution Check power cord connections. No Power Confirm that there is power at the outlet. -
Page 72: Map Of Screens (Remote Setup)
Operation Manual Map of Screens (Remote Setup) Remote Setup Quick Setup System Network Video Audio System General Date/Time User/Group Network IP Address Port/QoS Bandwidth Control Security IEEE 802.1X Video Camera Streaming Webcasting Privacy Masking Audio Input/Output Event Action Alarm Out Email Remote Callback Audio Alarm... -
Page 73: Specifications
Network Camera Specifications LENS Lens Type Varifocal optical zoom Focal Length F1.6 to F2.8, f=4.7 mm to 84.6 mm Angle View 64.9° (Wide) to 4.7° (Tele) – Diagonal Lens Iris Control DC auto-iris Day/Night Filter CAMERA Image Sensor 1/2.8" CMOS Minimum Illumination 0.5 Lux @ F 1.6 (30 IRE) - Page 74 Operation Manual INPUTS/OUTPUTS Video Output 1 Composite, 1 Vp-p Audio Input 1 line in Audio Output 1 line out 1 TTL, NC/NO programmable, 4.3V (NC) or 0.3V (NO) threshold, Alarm Input 5 VDC Alarm Output 1 relay out, NO only, 0.3A @ 125 VAC, 1A @ 30 VDC Network Connectivity 10/100 Mbps Ethernet It is intended for video preview while adjusting the camera.
-
Page 75: Index
Network Camera Index Admin/Watch/Record/Search Port ..21 ONVIF Protocol ........15 Pan/Tilt Driver ID ......40, 41 Bitrate Control ........30 Camera Name ......... 15, 19 Quality ..........30 Compression ........30, 32 Resolution ..........30 Date/Time ..........16 RTSP Port ..........21 DSCP .............
