Direct IP Network Camera Operation Manual page 74

Operation Manual
ii
Video Output
Audio Input
Audio Output
Alarm Input
Alarm Output
Network Connectivity
ii
It is intended for video preview while adjusting the camera.
iii
Video Output
Audio In/Out
Alarm In/Out
Ethernet Port
Power
iii
It is intended for video preview while adjusting the camera.
Dimensions (Ø x H)
Shipping Dimensions
(W x H x D)
Unit Weight
Shipping Weight
Operating Temperature
Operating Humidity
Power Supply
Power Consumption
Approval
iv
It is not supported for the flushed model.
68
INPUTS/OUTPUTS
1 Composite, 1 Vp-p
1 line in
1 line out
1 TTL, NC/NO programmable, 4.3V (NC) or 0.3V (NO) threshold,
5 VDC
1 relay out, NO only, 0.3A @ 125 VAC, 1A @ 30 VDC
10/100 Mbps Ethernet
CONNECTORS
Terminal block
Terminal block
Terminal block
RJ-45
DC Jack
(internal/external diameter: 0.098" (2.5mm) / 0.217" (5.5mm))
7.87" x 7.87" (200mm x 200mm)
10.83" x 12.6" x 10.83" (275mm x 320mm x 275mm)
5.40 lbs. (2.45kg)
7.94 lbs. (3.6kg)
Heater non-supported model: 14°F to 122°F (-10°C to 50°C)
(Boot up temperature: 32°F to 122°F (0°C to 50°C))
Heater supported model: -22°F to 122°F (-30°C to 50°C)
(Boot up temperature: 5°F to 122°F (-15°C to 50°C))
0% to 90%
Heater non-supported model: 12 VDC, 24 VAC, PoE (Power over
Ethernet) (IEEE 802.3af, Class 3)
Heater supported model: 12 VDC, 24 VAC, PoE (Power over
Ethernet) (IEEE 802.3at, Class 4)
Max. 8.5W (Max. 27.5W when the heater is operating)
FCC, CE, IP66
Specifications are subject to change without notice.
GENERAL
iv
