Cut off the power from the camera → Remove the dome cover and poke a straightened paperclip
into the factory reset switch hole. → Turn on the power while holding the reset switch → Release
the switch in about 5 seconds after the power is applied → The camera resets to factory defaults
and restarts after completing the factory reset → Reconnect the dome cover.
CAUTION: Make sure that the waterproof sealing is joined properly when reconnecting
the dome cover; otherwise, the IP66 level is not guaranteed.
You can perform a factory reset while the camera is turned on by pressing the factory reset switch
and releasing the reset switch. A factory reset also can be performed remotely by running the INIT
program. The camera restarts after completing the factory reset. Refer to the INIT User's Manual
for details on remote factory resetting.
WARNING: You might need to reinforce the wall or ceiling. If the wall or ceiling is
not strong enough to support the camera, the camera might fall damaging the camera
or causing injuries.
< Indoor >
10

Mounting

1. Screw the indoor bracket to the wall or ceiling by using
the mounting screws provided with the camera.
2. Hook the safety wire of the bracket on the safety wire
ring of the camera body.
3. Connect the external devices, network and power adapter.
4. Connect the camera body to the indoor bracket. Fix the
bracket setscrew of the camera body up to the bracket
setscrew hole and turn the camera body 25 degrees
clockwise.
5. Fasten the camera body to the bracket by tightening a
screw provided with the camera to the bracket fastening
screw hole of the bracket.
6. Apply power.
