Direct IP Network Camera Operation Manual page 36

Operation Manual
 Primary, Secondary, Tertiary, Quaternary: The camera supports multistream video (priority:
Primary > Secondary > Tertiary > Quaternary). Set whether to enable or disable the streams.
Some of the settings may change depending on the settings of streams of higher priority and
the tertiary and quaternary streams may not be available (see the table below).
< HD Model >
Primary
Resolution
1280x720
< Full HD Model >
Primary
Resolution
1920x1080
1920x1080
1920x1080
1920x1080
1920x1080
1920x1080
 Compression: Set up the compression of images for streaming.
 Resolution: Set the resolution of images for streaming. The resolution varies depending on the
camera model. The resolution of the current stream cannot exceed that of a stream of higher priority.
 Quality: Set up the quality of images for streaming.
 Bitrate Control: Set up the bitrate control mode for H.264 compression.
− CBR (Constant Bitrate): Maintains the current bitrate regardless of the amount of motion.
− VBR (Variable Bitrate): Adjusts the bitrate dynamically based on the amount of motion. The
less motion there is, the less network congestion and the less storage consumption. The quality
may not be as good when compared to the CBR mode
 Frame Rate: Set the frame rate of images for streaming. The frame rate of the current stream
cannot exceed that of a stream of higher priority if the resolution of the current stream is the same
as that of the stream of higher priority.
 Default Record Stream: Select a stream to use for recording. If a recording stream is set up
in a remote program or recording on an SD memory card is enabled in this camera, this setting
may not be applied. Refer to the Event Action – Record, Preference setup for details.
 Multi-View Streaming: It allows you to set up a streaming area to stream specific area of video
(not supported for the primary stream). Click the Setup button and set up the streaming area.
30
Secondary
ips Resolution
30 1280x720
Secondary
ips Resolution
30 1280x720
30 1280x720
30 704x480
30 704x480
15 1920x1080
15 1280x720
Tertiary
ips Resolution
15 –
Tertiary
ips Resolution
10 1280x720
10 352x240
–
30
15 704x480
15 704x480
30 1280x720
.
Quaternary
ips Resolution
– –
Quaternary
ips Resolution
–
1
–
10
–
–
–
15
–
30
–
15
ips
–
ips
–
–
–
–
–
–
