(2) eth0, eth1: Network interfaces
eth0 is used for network booting and hard disk mounting.
(3) Power port: Connector for AUX 12V 8-pin
This board is also compatible with 2x3 power connectors, please use the pins
outlined in blue when using a 2x3 connector.
Copyright © Fixstars Corporation. All rights reserved.
eth0(T1)
eth0(T1)
Power port (2x3pin)
Power port (2x3pin) Power port (2x4pin)
3
eth1(T2)
eth1(T2)
Power port (2x4pin)
