ARRANGEMENT OF THE INSTRUMENTS/CONTROLS

KEY
1) Clutch lever
2) Ignition/steering lock switch (
3) Instruments and indicators
4) Front brake lever
5) Throttle twistgrip
6) High beam flasher ( )/LAP button (multifunction)
use and maintenance RSV 1000 R - RSV 1000 R FACTORY
16
1
2
6
8
9 7
- - )
3
10 11
7) Light dimmer switch (
8) Direction indicator switch (
9) Horn button ( )
10) Starter button ( )
11) Engine kill switch (
