Chapter 3: SGI 1400 Server SCSI Backplane Installation
62
1
Figure 3-4
Reconnecting Cables to the New Backplane
Locations shown in Figure 3-4 are:
1.
Front panel cable
2. Peripheral power cable
3. SCSI Cable
2
