Chapter 1: Working Inside the System
8
Installing a PCI option Board
Figure 1-3
Components shown in Figure 1-3 are:
1. PCI or ISA slot
2. Six PCI slots (top to bottom in figure = PCI B4, B3, B2, B1, A3, and A2)
3. PCI slot A1 (Use five inch-length (12.7 cm) board only)
1
2
3
