Baseboard Connectors
Chapter 4
Technical Reference
This section includes:
•
Connectors' pinouts and baseboard locations
•
Information on baseboard jumpers
•
System I/O Addresses
•
System memory map addresses
•
Baseboard interrupts
•
Video modes
Figure 4-1 shows connector locations on the baseboard. This section provides pin
information about the connectors.
