Baseboard Jumpers
Baseboard Jumpers
One 11-pin single inline header provides three 3-pin jumper blocks that control various
configuration options. Figure 4-17 shows the location. Items shown in bold in Table 4-19
show default placement for each configurable option.
J6J1
11
7
3
1
Baseboard Jumpers
Figure 4-17
99
