Chapter 4: Technical Reference
80

Universal Serial Bus

The server provides a single, external Universal Serial Bus (USB) connector at the back
panel (see Figure 4-12) and an internal header to be used with device bay expansion.
Table 4-11 lists the pinouts for the external USB connector. Table 4-12 lists the pinouts for
the internal USB header.
4
1
Figure 4-12
USB External Connector
Table 4-11
USB External Connector Pinout
Pin
Signal
1
VCC
2
Data -
3
Data +
4
GND
Table 4-12
USB Internal Header Pinout
Pin
Signal
1
2
Data -
3
Data +
4
GND
Notes
Cable power
Data (differential pair negative)
Data (differential pair positive)
Cable ground
Notes
N/C
Data (differential pair negative)
Data (differential pair positive)
Cable ground
