Timecode Source Page; Timecode Output Enable Page; Group Id Page; Unit Id Page - Zaxcom ZFR100 User Manual

Zaxcom Miniature Digital Recorder User's Manual____________________________________Chapter 2
o If an STAxxx/TCA100 is being used and the timecode source is connected to it when the timecode
AUTO-JAM
MANUAL (OFF)
IMPORTANT: While you are controlling the recorder using ZaxNet, or directly from the IFB100, you would be
wise to use
mere act of scrolling past the
unless you are watching the LED indicator, you won‟t have visual confirmation.

Timecode Source page

TC SOURCE:
IFB (RF)
Page purpose:
Parameters:
SIDE CONNECTOR
IFB (RF)
AUDIO INPUT

Timecode Output Enable page

TIMECODE OUTPUT:
OFF
Page purpose:
Parameters:
ON: OUT BOTH
ON: OUT RIGHT
ON: OUT LEFT
OFF

Group ID page

REMOTE CONTROL
GROUP ID=1
Page purpose:
Parameters:
It is highly desirable to have all transmitters and recorders in a given group assigned to the same IFB100.

Unit ID page

REMOTE CONTROL
UNIT ID=001
Page purpose:
Parameters:
(valid range:
ALL
When using the IFB100, this identifier is used to remotely control one specific unit out of the entire group. This
information is also useful in Post to identify the unit since it is recorded in the BWF metadata.
source starts and stops.
– continuously jams timecode, based on the
– jam timecode once, based on the
AUTO-LOAD
here. If it becomes necessary to make changes using the unit‟s menu buttons, the
Transport Control page
This page maintains which input to use as the timecode source.
– Accept a timecode source connected to the attached STAxxx‟s side connector.
– Accept a timecode source connected to the IFB100.
– Accept a timecode source connected to the Audio Input connector.
This page enables/disables timecode output and specifies the output connector.
– Sends timecode to both (attached STAxxx‟s TC output & headphone output).
– Sends timecode to the attached STAxxx‟s timecode output connection.
– Sends timecode to the headphone output.
– Timecode is not output.
This page identifies which IFB100 can remotely control this unit.
0 99
(valid range: to
This page maintains the number used to uniquely identify this unit.
1 200
to , value step:
{p.21}, will immediately put it in RECORD mode and
1
, value step: )
1
)
29
Timecode Source page
Timecode Source page {p.29} selection.
{p.29} selection.
