Zaxcom Miniature Digital Recorder User's Manual____________________________________Chapter 6

ZFR200 Specifications

Recorder Audio
Dynamic Range
Distortion
Frequency Response
Highpass Filter
Mic Power
Mic Connector
Input Range
Impedance
ADC Bit-depth
ADC Sampling-rate
Timecode Reader/Generator
Clock Accuracy
Timecode Type
Timecode Frame-rates
Recording
Media
File Format
Recording Time
IFB Receiver (optional)
RF Frequency Range
RF Modulation
RF Frequency Step
RF Bandwidth
Channel Separation
Sensitivity
DAC Bit-depth
DAC Rate
Frequency Response
Output Impedance
Physical
Weight
Dimensions (H x W x D)
External Power (STAxxx)
Internal Power (Battery)
Display
103 dB
0.001%
20 Hz to 16 kHz
„OFF‟ or 30 to 220 Hz, step: 10 (6 dB per octave)
3.3 VDC @ 10mA max
3-pin micro-LEMO (mic side = FGB.00.303.CLAD.22)
–60 to –24 dBu
4.7 k ohms
24 bits
48 kHz
1.54 PPM (1 frame out in 6 hours)
SMPTE
23.98, 24, 25, 29.97NDF, 29.97DF, 30NDF, 30DF
MiniSD card (Flash memory)
.ZAX
96 hours (16 GB card)
2.403 to 2.475 GHz
Digital Spread Spectrum
0.001 GHz (1 MHz)
1 MHz
2 MHz
-96 dBm
24 bit
48 kHz
20 Hz to 12 kHz
8-ohm minimum
3.1 oz (88 grams) without battery
2.38" x 2.38" x 0.69" (60 mm x 60 mm x 17 mm)
N/A
up to 8 hours (one AA Lithium)
Graphic LCD panel
43
