Chapter 8____________________________________Zaxcom Miniature Digital Recorder User's Manual
Fixed TC Reader no longer jams on seconds boundary
===================================================================================================================
Version 5.33a: UNKNOWN
Changed Loosened jam requirements
===================================================================================================================
Version 5.20: 2008-03-07
Added Higher resolution transmit waveform to increase TX range
===================================================================================================================
Version 5.19: 2008-02-29
Added Timecode display in Lock page
Added Timecode debug codes to Debug page
Fixed 23/24/25 fps TC reader problems
Fixed Transmitter‟s name initialization (was always NLD by default now it's SN#####)
===================================================================================================================
Version 5.17: 2008-02-18
Fixed Timecode problem with 23.98, 24 and 25fps timecode. This was causing autoload to trigger several times in a take. This version should be
used in an IFB transmitter if using the wireless autoload feature
===================================================================================================================
Version 5.13: 2007-12-18
Added Low battery warning text on Pacifier page
Added Expander page (experimental version)
Added Battery Type page (LITHIUM, ALKALINE and NIMH) NIMH needs some tweaking
Added Voltage display in Pacifier page (press INC key)
Added 500ms delay in Audio Gain page to prevent accidental gain change when leaving the Lock page
Added Support for Non-Loop Record mode
Added "FULL" message to Pacifier page for Non-Loop Record mode
Changed Lock page to prevent unintended GAIN changes
Fixed Left/right audio channel swap problem (effected only some units)
Modified IFB100 – IFB Transmitter Power page to Extended Menu to adjust transmitter output power
===================================================================================================================
Version 5.04: 2007-11-12
Fixed Stereo TONE transmit problem (*since 5.02)
===================================================================================================================
Version 5.03: 2007-11-09
Added Accurate voltage display on the Pacifier page and Audio Gain page (press DOWN or UP key)
Added IFB100 - IFB Transmitter Power page (range = 0 to 7)
Modified Low Power mode triggers a new experimental Low Power mode.
This mode is triggered if:
LED mode = "LOW POWER MODE"
TX Format = US (MONO)
IFBMODE = "OFF"
Timecode, IFB and Recording features are turned „OFF‟ in this mode
To change to Low Power mode:
1.
2.
3.
4.
5.
===================================================================================================================
Version 5.00d: UNKNOWN
Added Timecode wrap at 24 hours for non-jammed timecode setting using last recorded segment as TCjam
Fixed a serious record bug that prevented the unit from going into record if the timecode had wrapped around the 24-hour mark.
===================================================================================================================
Version 5.00b: UNKNOWN
Added Special super Low Power operating mode: It is triggered if:
Changed battery meter table
===================================================================================================================
Version 5.00a: 2007-11-03
Go to Extended Menu (hold MENU while powering up the unit)
Change IFB Mode page to „OFF‟ (if you have that option)
Go to the LED Reverse page (one of the last menu pages). The LED Reverse page allows you to change the default color of the
LED. The LED should usually be green.
Change the setting to LED LOW PWR MODE while keeping the LED Reverse setting the same digit as it was previously.
If the conditions have been met, the unit will display LOW POWER MODE, IFB IS OFF when the unit boots up again and the LED
turns „OFF‟ when not in use. This setting should increase the battery life by over 15% depending on the chemistry of the batteries
you are using.
LED mode = LOW POWER MODE
TX Format = US (MONO)
(NOTE: no timecode, IFB or recording is available in this mode)
