Chapter 6____________________________________Zaxcom Miniature Digital Recorder User's Manual

ZFR800 Specifications

Recorder Audio
Dynamic Range
Distortion
Frequency Response
Highpass Filter
Mic Power
Mic Connector
Input Range
Impedance
ADC Bit-depth
ADC Sampling-Rate
Timecode Reader/Generator
Clock Accuracy
Timecode Type
Timecode Frame-rates
Recording
Media
File Format
Recording Time
Physical
Weight
Dimensions (L x Dia)
External Power
Internal Power (Battery)
Display
103 dB
0.001%
20 Hz to 16 kHz
„OFF‟ or 30 to 220 Hz, step: 10 (6 dB per octave)
9 VDC
Compatible with Shure™ screw-on microphone capsules
-60 to -30 dBu
10 k ohms
24 bits
48 kHz
1.54 PPM (1 frame out in 6 hours)
SMPTE
23.98, 24, 25, 29.97NDF, 29.97DF, 30NDF, 30DF
MiniSD card (Flash memory)
.ZAX
96 hours (16 GB card)
8.2 oz (232 grams) without a battery and mic capsule
6.12" x 1.5" (155mm x 38mm) without windscreen and mic capsule
N/A
up to 10 hours (one CR123)
Graphic LCD panel
44
