Chapter 1____________________________________Zaxcom Miniature Digital Recorder User's Manual

Compatible Lavs

RF Resistant Lavs

Use one of the following microphone models:
Additional microphones will be added to this list after a review of their 3.3v power performance and RF
interference susceptibility has been completed.

Non-RF Resistant Lavs

Use one of the following microphone models:
Additional microphones will be added to this list after a review of their 3.3v performance.

General

The ZFR100 / ZFR200 has an unbalanced microphone input accessed through a 3-pin micro-LEMO connector.
You can use an unbalanced dynamic microphone or a powered lavaliere. It is recommended that you use 3-wire
lavalieres with separate pins for ground, audio and power.
When using a line-level input, an inline pad is required on the standard dynamic microphone input cable (XLR-3 to
3-pin micro-LEMO).
When using a phantom powered microphone with the ZFR100 / ZFR200, you must use an external 48 VDC
power supply.
NOTE: Once upon a time, the Denecke 48V power supply could damage the now discontinued Goldline
transmitter‟s preamp. This is NOT the case with the ZFR100 / ZFR200.
Brand
Countryman B6
Countryman B3
Countryman E6 omni
Countryman EMW
DPA 4063-BMZ
Sanken COS-11D
Sennheiser MKE-2 Platinum
Sennheiser MKE-2 Gold
Shure WL50
Sony ECM77
Tram TR-50
Voice Tech. VT401HS
Voice Tech VT506
Voice Tech. VT910

Table 1-2 Compatible RF Resistant Lavalier Microphones

Brand
Audio-Technica 892*CL4
Audio-Technica 898*L4
Audio-Technica 899*L4
Isomax Instrument
Countryman
M2H*W3
Isomax Instrument
Countryman
M2C*W3
DPA Headband 4067

Table 1-3 Compatible Non-RF Resistant Lavalier Microphones

Model Voltage
1.5
1.5
3
3
3
5
Model Voltage
3
3
3
3
1.5
3
10
Notes
Specify for use with Zaxcom
Use only the Zaxcom 3.3 V model
New model – YES.
Older models – NO
Notes
Hypercardioid
Cardioid
Other headband requires 5 volts
