Zaxcom Miniature Digital Recorder User's Manual____________________________________Chapter 1

Battery Installation

Each unit may require one or two batteries.
CAUTION: Always observe the correct battery polarity. The negative contact on the battery is always
connected to the spring contact.
Never use any battery that is missing insulation on its body. If you do, it can cause a short circuit in the
battery compartment, causing damage to the unit.

Battery Life

IMPORTANT: If operating using internal batteries, it is recommended that you use only Lithium or
rechargeable NiMH. Any other battery chemistry including Alkaline and Ultra batteries have a substantially
reduced runtime compared to Lithium or NiMH cells. This is true for all Zaxcom units.

External Power

Some of the units can be powered from an external power source. The external power connection is a 2.5 mm
(0.1") barrel connector. The center pin is positive. The connector for the STAxxx and IFB100 is the Switchcraft
760K.

Common Settings for Associated IFB Transmitter and Receivers

The following settings must agree, to allow associated IFB transmitters and receivers to work together,
(this assumes that the same or compatible versions have been installed in all units):
Extended Menu
Allow IFB Remote Control page
IFB Signal Format page
IFB Receiver Enable page
Group ID page
Unit ID page
IFB Frequency page

IFB Antenna

CAUTION: The location(s) of the antenna(s) are indicated in the images for each unit. Don‟t place anything in
front of this area that could block reception. Also, don‟t allow anything to press in on this area, the antenna
and/or receiver could be damaged.
Associated Products User's Manuals
Zaxcom Digital Wireless System, IFB & Remote Control – User‟s Manual
Zaxcom ZaxConvert Utility – User‟s Manual

Product Support

Download the latest Firmware from:
Download the latest User Manuals from: http://www.zaxcom.com/support_instructional_manuals.htm.
Register your new Zaxcom Product at:
Submit Technical Questions at:
Request an RMA # at:

Figure 1-2 External Power Polarity

IFB Receiver side

Table 1-4 IFB Settings that Must be Consistent

IFB Transmitter side
Extended Menu
IFB Signal Format page
Group ID page
Standard Menu
Remote Unit ID page
IFB Frequency page
http://www.zaxcom.com/support_software_updates.htm.
http://www.zaxcom.com/support_product_registration.htm.
http://www.zaxcom.com/support_submit_tech_questions.htm.
http://www.zaxcom.com/support_repair_services.htm
