Chapter 9____________________________________Zaxcom Miniature Digital Recorder User's Manual
MENU SETTINGS
Standard Menu
(Transport Control page
i.
While in STOP, press the DEC key to move the playback pointer backward.
To PLAY, press the INC key.
While in PLAY, press the INC key to move the playback pointer forward.
ii. GAIN: ________
(0 to 36 dB, step 2)
iii. HIGH PASS: ________
([OFF] / [valid range: 30 to 220Hz, value step: 10])
iv. LIMITER: ________
([OFF] \ [valid range: -2 to -30dB, value step: 1])
v. TIMECODE: ________
([23.98] / [24] / [25] / [29.97NDF] / [29.97DF] / [30NDF] / [30DF])
vi. PRESS UP KEY 5X
(Lock page
vii. LOCK
(5 sec countdown once entered)
(To unlock, simultaneously press the MENU & INC keys)
Extended Menu – to reach these, turn 'OFF' the TX and hold the MENU key down while powering up.
(Displays EXTENDED MENU PRESS UP TO EXIT)
i. HIGH PASS: ________
([OFF] / [valid range: 30 to 220Hz, value step: 10])
ii. LIMITER: ________
([OFF] \ [valid range: -2 to -30dB, value step: 1])
iii. POWER UP MODE: ________
([UNLOCKED] / [LOCKED])
iv. PRESS UP KEY 5X
To Format a Card:
(See
v. TIMECODE OUTPUT: ________
([OFF] / [ON: OUT LEFT] / [ON: OUT RIGHT] / [ON: OUT BOTH])

Menu Sheet for ZFR800

{p.21})
(Audio Gain page
{p.21})
(Highpass Filter page
(Limiter page
{p.22})
(Timecode Frame-rate page
(Format Recording Card page
{p.24})
(Highpass Filter page
(Limiter page
{p.25})
(Power-up Mode page
(Format Recording Card page
{p.23} for additional information.)
(Timecode Output Enable page
{p.22})
{p.22})
{p.23})
{p.25})
{p.27})
{p.28})
68
{p.29})
