Chapter 9____________________________________Zaxcom Miniature Digital Recorder User's Manual
MENU SETTINGS
Standard Menu
(Transport Control page
i.
While in STOP mode, press the DEC key to move the playback pointer backward.
To PLAY, press the INC key.
While in PLAY, press the INC key to move the playback pointer forward.
ii. GAIN: ________
(0 to 36 dB, step 2)
iii. HIGH PASS: ________
([OFF] / [valid range: 30 to 220Hz, value step: 10])
iv. LIMITER: ________
([OFF] \ [valid range: -2 to -30dB, value step: 1])
v. TIMECODE: ________
([23.98] / [24] / [25] / [29.97NDF] / [29.97DF] / [30NDF] / [30DF])
vi. TC JAM MODE: ________
([MANUAL (OFF)] / [AUTO-JAM] / [AUTO-LOAD])
vii. TC SOURCE: ________
([AUDIO INPUT] / [IFB (RF)] / [SIDE CONNECTOR])
viii. IFB EARPIECE: ________
([REC/PLAY] / [IFB RX AUDIO] / [IFB MIX ALL] / [IFB MIX REMOTE])
ix. PRESS UP KEY 5X
(Lock page
x. LOCK
(5 sec countdown once entered)
(To unlock, simultaneously press the MENU & INC keys)
Extended Menu – to reach these, turn 'OFF' the TX and hold the MENU key down while powering up.
(Displays EXTENDED MENU PRESS UP TO EXIT)
i. HIGH PASS: ________
([OFF] / [valid range: 30 to 220Hz, value step: 10])
ii. LIMITER: ________
([OFF] \ [valid range: -2 to -30dB, value step: 1])
Chapter 9 – Menu Sheets

Menu Sheet for ZFR100

{p.21})
(Audio Gain page
{p.21})
(Highpass Filter page
(Limiter page
{p.22})
(Timecode Frame-rate page
(Timecode Jam Mode page
(Timecode Source page
(Earpiece Source page
(Format Recording Card page
{p.24})
(Highpass Filter page
(Limiter page
{p.25})
{p.22})
{p.22})
{p.22})
{p.23})
{p.23})
{p.23})
{p.25})
60
