Chapter 2____________________________________Zaxcom Miniature Digital Recorder User's Manual

Timecode Jam Mode page

TC JAM MODE:
MANUAL (OFF)
Page purpose:
Parameters:
 AUTO-LOAD
o If an IFB100 is being used - when the IFB100 timecode starts and stops.
o If an STAxxx/TCA100 is being used and the timecode source is connected to it when the timecode source
starts and stops.
 AUTO-JAM
 MANUAL (OFF)

Timecode Source page

TC SOURCE:
IFB (RF)
Page purpose:
Parameters:
 SIDE CONNECTOR
 IFB (RF)
 AUDIO INPUT

Earpiece Source page

IFB EARPIECE:
IFB RX AUDIO
Page purpose:
operation.
Parameters:
 IFB MIX ALL
 IFB RX AUDIO
 REC/PLAY
Media Erase & Format page
PRESS UP KEY 5X
TO ERASE CARD
SUCCESS (REBOOT)
#### MBYTES
FORMAT FAILED
ERROR ##
Page purpose:
This must be done before the card can be used (or to erase the contents) in the recorder.

To Format a Card:

1. Before formatting the card, enter the name
2. With the power „OFF‟, insert the memory card into the media slot with the label to the back of the unit. Press
it all the way in; it will lock down.
3. Press and hold the MENU key while the recorder is powered up.
4. Repeatedly press the MENU key until the screen displays
This page maintains how received timecode will be used.
– start and stop the recorder, based on the
– continuously jams timecode, based on the Timecode Source page selection.
– jam timecode once, based on the Timecode Source page selection.
This page maintains which input to use as the timecode source.
– Accept a timecode source connected to the attached STAxxx‟s side connector.
– Accept a timecode source connected to the IFB100.
– Accept a timecode source connected to the Audio Input connector.
ZFR100 ONLY – This page establishes the source for the audio being monitored during
– the earpiece receives its audio from both the media and the IFB receiver.
– the earpiece receives its audio from the IFB receiver.
– the earpiece receives its audio from the media.
This page erases and formats a MiniSD card.
(Track Name page {p.29}) to be used for this card.
PRESS UP KEY 5X TO ERASE CARD
20
Timecode Source page {p.20} selection:
.
