Zaxcom Miniature Digital Recorder User's Manual____________________________________Chapter 2

IFB Frequency page

FREQ: 2.403 RX
SIGNAL: 01
Page purpose:
antennas in a numerical and graphical format.
Parameters:
While a valid signal is received, the RX flag is displayed on the right side of the top line.
IFB Dropout Compensator page
IFB DROPOUT
COMPENSATOR ON
Page purpose:
Parameters:
Drop out compensation looks at the received audio data surrounding a short duration drop out. It intelligently
replaces the lost audio that will match together the audio surrounding the drop out. This eliminates any noticeable
distortion that would be caused by the missing audio data. This improves the performance of digital wireless as
interfering signals and drop outs of short duration have no effect on received audio quality. It will also fade out the
received audio smoothly when the transmitter is turned „OFF‟ or if the receiver goes out of the transmitters range.
Single drop outs of up to 30MS are very effectively eliminated. If the drop out is longer the audio begins to fade
out smoothly. If there are multiple drop outs over a longer period the compensation can do a good job of hiding
the problem as long as there is audio in between to process.

Power-up Mode page

POWER UP MODE:
UNLOCKED
Page purpose:
Parameters:
LOCKED
UNLOCKED
The Lock page
after the countdown clock has expired), the keys will be locked and it will be necessary to unlock them before you
can view/change anything.

Unlocking the Unit

Simultaneously press the MENU and INC keys. Once it is unlocked, the screen will display the
Control page
.
This page maintains the IFB receiver‟s center frequency and displays the signal strength for the
2.403
(valid range: to
(requires IFB Audio Option)
This page enables/disables Dropout Compensation on the IFB audio.
OFF ON
[ ] / [ ]
This page determines whether the keys will be consistently locked after power-up.
– After power-up has completed, the menu repositions to the
– The keys are unlocked upon power-up.
{p.24} is the gate keeper. Once
{p.21}.
2.475
GHz, value step:
LOCKED
is selected, every time the unit is powered up (and
27
0.001
)
Lock page {p.24}.
