Zaxcom Miniature Digital Recorder User's Manual____________________________________Chapter 9
iii. 1K NOTCH FILTER: _____
([OFF] \ [ON])
iv. 1K NOTCH FREQ: _____
(valid range: 960 to 1040 Hz, value step: 2)
v. RECORD FORMAT: _____
([STEREO] \ [MONO(US)])
vi. IFB FORMAT: _____
([LOW Q] / [HIGH Q])
vii. RXMODE: ________
([OFF] / [RX])
viii. IFB VOTING: ________
([NORMAL (OFF)] / [2 TXERS (ON)])
ix. FREQ: ________
(valid range: 2.403 to 2.475 GHz, value step: 0.001)
x. IFB DROPOUT COMPENSATOR: ________
([OFF] / [ON])
xi. POWER UP MODE: ________
([UNLOCKED] / [LOCKED])
xii. PRESS UP KEY 5X
To Format a Card:
(See
xiii. TC JAM MODE: ________
([MANUAL (OFF)] / [AUTO-JAM] / [AUTO-LOAD])
xiv. TC SOURCE: ________
([AUDIO INPUT] / [IFB (RF)] / [SIDE CONNECTOR])
xv. TIMECODE OUTPUT: ________
([OFF] / [ON: OUT LEFT] / [ON: OUT RIGHT] / [ON: OUT BOTH])
xvi. REMOTE CONTROL GROUP ID: ________
(valid range: 0 to 99, value step: 1)
xvii. REMOTE CONTROL UNIT ID: ________
([ALL] / [valid range: 1 to 200, value step: 1])
xviii. EXPANDER
PARMS: ([OFF] / [ON])
(1K Notch Filter Enable page
(1K Notch Filter Frequency page
(Recording Format page
(IFB Signal Format
(IFB Receiver Enable
(IFB Voting Enable page
(IFB Frequency page
(Power-up Mode page
(Format Recording Card page
{p.23} for additional information.)
(Timecode Jam Mode page
(Timecode Source page
(Expander page
{p.30})
{p.26})
page
{p.26})
page
{p.26})
{p.26})
{p.27})
(IFB Dropout Compensator page
{p.27})
{p.28})
{p.29})
(Timecode Output Enable page
(Group ID page
(Unit ID page
61
{p.25})
{p.25})
{p.28})
{p.29})
{p.29})
{p.29})
{p.27})
