Chapter 2 – Digital Wireless System Transmitters
This chapter is intended to quickly familiarize you with the functions of each of the Digital Wireless System
transmitters and was written based on firmware version

Getting to Know Your ZFR100 Bodypack Recorder

The ZFR100 uses two AA batteries (Lithium or NiMH).

Compatible Lavs

RF Resistant Lavs

Use one of the following microphone models:
1. 2. 3. 4.
1. REC Key
2. MiniSD Media Slot
3. Power/Record LED
4. STOP Key
5. Power Switch
6. PLAY Key

Figure 2-1 ZFR100 Top and Front Views

Brand
Countryman B6
Countryman B3
Countryman E6 omni
Countryman EMW
DPA 4063-BMZ
Sanken COS-11D
Sennheiser MKE-2 Platinum
Sennheiser MKE-2 Gold
Shure WL50
Sony ECM77
Tram TR-50
Voice Tech. VT401HS
Voice Tech VT506
Voice Tech. VT910

Table 2-1 Compatible RF Resistant Lavalier Microphones

6.10.
5. 6. 7.
7. Microphone/Timecode Input
8. LCD Screen
9. INC Key
10. DEC Key
11. MENU Key
12. Battery Door and Compartment (on back)
Model Voltage
1.5
1.5
3
3
3
5
11
Notes
Specify for use with Zaxcom
Use only the Zaxcom 3.3 V model
New model – YES.
Older models – NO
8.
9.
10.
11
12.
