Valve Guides Specification

9.612.0.006.7160 - 05/04
Ø (A)
After assembly
Nominal
Repair
Maximum
Ø (B)
Outer
Nominal
Ø (C)
Housing
Nominal
Ø (D)
Clearance at the Stem
Nominal
Maximum
(mm)
9.000 - 9.022
9.013 - 9.028
9.060
(mm)
15.028 - 15.039
(mm)
14.991 - 15.021
(mm)
0.030 - 0.070
0.111
Cylinder heads
