Pistons and Connecting Rods

Piston and Pin

Piston Pin
Diameter
Nominal
Maximum
Connecting Rod Bushing (assembled)
Diameter
Nominal
Maximum
Connecting Rod Bushing (housing)
Diameter
Nominal
Piston Pin
Clearance
Nominal
Maximum
ØA
(mm)
37.994 to 38.000
37.900
ØB
(mm)
38.030 to 38.080
38.140
ØC
(mm)
41.000 to 41.016
ØD
(mm)
0.030 to 0.086
0.150
9.612.0.006.7160 - 05/04
