Tightening Torques Specification for Components of the Lubrication System

25 ± 4 Nm
20 ± 3 Nm

Tightening Torques Specification for Oil Cooler Connections

20 ± 3 Nm
9.612.0.006.7160 - 05/04
25 ± 4 Nm
65 ± 10 Nm
25 + 5 Nm
Lubrication System
Tighten sequence
15 13 7 5 1 3
9 11 17
16 14 8 6 2 4 10 12 18
25 ± 2 Nm
20 ± 3 Nm
