MWM Acteon Workshop Manual page 12

Technical Data
Engine Data
Engine type
Injection type
Cylinder bore
Cylinder stroke
Unit displacement
Total displacement
Quantity of cylinders
Compression rate
Firing order
Rotation sense
Dry engine weight
Power
Torque
Valves clearance (cold)
Description
Maximum fuel inlet
restriction (for gears
pump)
Rail pressure
Fuel pressure strip in the
fuel filter outlet (at crank
speed)
Strip of fuel pressure in
fuel filter fuel inlet (at
operation speed)
Maximum pressure
reduction in fuel filter
Technical Data
4.12TCE
Vertical cylinders in line, 4 strokes
Direct with electronic management
105 mm
137 mm
4,745 litres
4
1 - 3 - 4 - 2
Counter clockwise (seen by flywheel side)
~450 Kg
150 hp
105 kW
500 Nm
0,2 to 0,4 mm
Fuel System
4 Cylinders
0.6 to 1.2 bar
350 to 1400 bar
9.7 to 12.8 bar
10,5 to 13 bar
≤ 0,8 bar
6.12TCE
1,2 l
7,118 litres
6
16,8:1
1 - 5 - 3 - 6 - 2 - 4
~570 Kg
210 hp
152 kW
700 Nm
6 Cylinders
260 hp
191 kW
900 Nm
9.612.0.006.7160 - 05/04
