Liner Protrusion Specification

Thickness
9.612.0.340.002.4
Thickness
9.612.8.340.004.4
9.612.8.340.005.4
9.612.8.340.006.4
9.612.8.340.007.4
9.612.0.006.7160 - 05/04

Pre-Assembly Inspections and Measurements

Liner over Engine Block Surface
Measure
Protrusion
*Affect emissions level
TOMBAK Ring
Protrusion Adjustment Shims (when necessary)
mm
*0.04 - 0.09
mm
0.15
mm
0.05
0.10
0.20
0.50
Engine Block
