Valcom V-WMCA Instruction Manual page 28

Valcom Master Clock
Gateway IP Address - This field allows the user to set the Gateway IP address for the master clock.
1
Subnet Mask - This field allows the user set the Subnet Mask for the master clock.
2
IP Address - This field allows the user to set the IP address for the device.
3
DNS Router - This field allows the user to set the DNS Router address. The default address will typically work for
4
most applications, however some modification may be needed for certain networks.
DHCP - This drop down list allows the user to turn DHCP on or off. DHCP allows the master clock to look for an IP
5
address on its own if the network has a DHCP server.
Device Name - This field allows the user to name the device a unique name.
6
Submit - This button, when pressed, will save all of the information to the master clock.
7
Cancel - This button, when pressed, will clear out any changes made and will not save any data.
8
Menu - This button, when pressed, will bring the user back to the main menu.
9
(V2)
Web Browser Programming
IP Settings Page 1 (cont.)
Page 28
