Valcom Master Clock

Programming the Valcom Master Clock

Programming may be accomplished manually or through the web interface. See page 19.
To set the time, press the top button to change the hour and/or the bottom button the set the minute.
Fig 2.1
*Press both buttons on the front panel simultaneously to enter programming mode.*
(V2)

Setting the Time from the LED Display

See Fig 2.1.
Once programming mode has been entered, the
number "1" will appear in the far left position. This
prompt allows the user to set the year. Use the
bottom button to scroll from "00-99" on the dis-
play and set the year.
Press the top button to enter option 2. The number
"2" will appear on the left side of the LED display.
This prompt allows the user to set the month. Use
the bottom button to scroll between "01-12".
Set Hour
Set Minute
Page 11
