Valcom Master Clock
(V2)

Patch Cable Installation

Fig 1.1
Wall Jack to
Network
1) Connect a patch cable to the RJ45 port on the Valcom Master Clock as shown in Fig 1.1.
2) Connect the other end of the patch cable to an Ethernet jack connected to the network.
