Valcom Master Clock
(V2)
Press the top button to enter option 3. The number
"3" will appear on the left side of the LED display.
This prompt allows the user to set the day. Use the
bottom button to scroll between "01-31".
Press the top button to enter option 10. The num-
ber "10" will appear on the left side of the LED
display. This prompt allows the user to enter into
technical mode. If technical mode is desired, press
the bottom button until "08" is reached. Setting
option 10 to "08" will allow the user access to op-
tions 11-13 when the top button is pressed. Any
other value will go directly to option "20" when the
top button is pressed.
Press the top button to enter technical mode which
starts with option 11. The number "11" will appear
on the left side of the LED display. This prompt allows
the user to set the data transmission for the RS485.
Press the bottom button to scroll between "01-12".
01 - Data is transmitted every second
02 - Data is transmitted every 5 seconds
03 - Data is transmitted every 10 seconds
04 - Data is transmitted every 15 seconds
05 - Data is transmitted every 30 seconds
06 - Data is transmitted every minute
Press the top button to enter option 12. The num-
ber "12" will appear on the left side of the LED
display. This option allows the user to enable or
disable Daylight Savings Time. Press the bottom
button to scroll between "d", "1", or "2". "d" will
disable this option. "1" will enable daylight savings
pre 2007. "2" will enable daylight savings post
2007.
07 - Data is transmitted every 2 minutes
08 - Data is transmitted every 5 minutes
09 - Data is transmitted every 10 minutes
10 - Data is transmitted every 15 minutes
11 - Data is transmitted every 30 minutes
12 - Data is transmitted every hour
Page 12
