i-on16

Power Supply

This product complies with the requirements of EN50131-
6 Type A power supply at Grade 2 and environmental
class 2.
Mains power supply
End station psu
End station consumption
Communicator consumption 50mA max
Keypad consumption
Standby Battery
Battery charge limit
12V Aux supply (inc LS)
14V4 supply
12V Keypad bus
Monitoring includes

Electromagnetic Compatibility

Immunity
Emissions

Outputs

O/P 1 - 4
LS (loudspeaker)
Technical Specification
230VAC +10%/-15%, 170mA
max, 50Hz.
13.7VDC, 1.5A max
145mA.
30mA (backlight off)
45mA (backlight on)
65mA (backlight on max)
12V, 7Ah sealed lead acid.
Standby time: more than 12
hours.
Max recharge time: less than
72 hours.
270mA
13.7VDC +0.1/-0.4 @ 850mA
max.
14.4V +0.1/-0.2 @ 230mA
13.7V =0.1/-0.5 @ 400mA
max
Mains fail, battery low
voltage, battery failure.
Conforms to EN50130-4.
Conforms to EN61000-6-3.
Open collector transistor,
+12VDC when inactive, 0V
when active. 500mA max.
See page 37 for programming
details.
Min impedance 16 Ohm,
current consumption from
12VAux = 280mA in alarm.
Page 7
