- Page 1 MENVIER SECURITY...
- Page 2 Printed and published in the U.K. This manual applies to the Menvier300 control unit with version 4.03 software. For Your Safety This book contains several passages alerting you to potential problems or hazards. Each of these are marked by the words Note, Caution or WARNING.:...
-
Page 3: Table Of Contents
Menvier300 CONTENTS Step 9. Fit and Connect Battery .... 17 Step 10. Initial Power-Up ......17 Transferring to Another Keypad ..19 1. Introduction ........1 Leaving the Installer Menu ....19 Communications ......... 1 Important! Saving Changes ....20 Level Setting or Ward Based System .. - Page 4 Menvier300 This page is intentionally blank. Page iv...
-
Page 5: Introduction
A speech dialler and public 1. Introduction (ATS2) switched telephone network (PSTN) module that allows the The Menvier300 is a control unit for a control unit to send recorded hybrid wired/wirefree alarm system speech messages and report intended for domestic, commercial or alarm information using industrial use. -
Page 6: Installer Programming Interface
Please read the 790r manual for details. laptop to the mini USB port on the control Please be aware of the following: unit PCB and use Cooper Security‟s Downloader software to program the The 790r signal strength meter readings ... -
Page 7: Siting The Control Unit And Wired Zone Expanders
The total weight of the control unit plus batteries can be up to 18kg. CAUTION: All printed circuit boards for the Do site the unit: Menvier300, its expanders and keypads have been tested for Electromagnetic Upright, batteries at the bottom. (This Compatibility (EMC). However, when... - Page 8 Before You Begin Menvier300 1. Case back. 2. Cable entry holes for -LS1+ -LS2+ AUX STB BELL TR 14V4 TAMP BELL loudspeakers, siren/strobes and communicators. 3. Fixing holes. 4. Plastic PCB tray. KICKSTART 5. Printed circuit board (PCB). 6. Cable entry holes for detector...
-
Page 9: I-Kp01 Controls And Displays
Menvier300 Before You Begin i-kp01 Controls and Displays 1. Central keyhole. 1. LCD display (2 x 20 characters). 2. Rear tamper shroud. 2. Programming keys. 3. Cable entry. 3. Navigation keys 4. Fixing holes. 4. Alert LEDs Figure 7 Keypad Rear Housing 5. - Page 10 Before You Begin Menvier300 1. Cable entry (also behind PCB). 2. Fixing holes. 3. Addressing button. 4. Bus cable connector. 5. Central keyhole. 6. Outputs. 7. Aux power. 8. Lid tamper (rear tamper behind pcb). 9. Bus address display. 10. Zone connectors.
-
Page 11: Power Availability
Use one pair for data lines A and B. Use the example: in an alarm system with an other pair for 12V and 0V. For optimum Menvier300 control unit, five i-kp01 performance the voltage at the keypads keypads, three expanders and 40 wired and expanders should be greater than 12V. -
Page 12: Cable Configuration And Length
If there are more than two arms BUT Bus Termination each cable is more than 10m then DO The Menvier300 bus uses the RS485 NOT fit the termination jumpers on any interface. Because of this the ends of the of the devices. - Page 13 Reducing Voltage Drop - Method 2: to the bus, otherwise an earth fault will Supply the detection devices from the Aux occur. Cooper Security recommend the output on separate cores. This is the EXP-PSU. When installing a remote power preferred method of reducing voltage drop...
-
Page 14: Installation
Menvier300 WARNING Ensure that the fixings are 3. Installation strong enough to support the weight of the control unit, its lid and two 17Ah lead acid Note: The installation steps listed below batteries. The total weight of the control assume that you have already decided on unit plus batteries can be up to 18kg. -
Page 15: Fitting Keypads
Menvier300 Installation their prox readers will interfere and be The set/unset LEDs ABCD-ON ABCD-ON ABCD-ON unable to read tags. are disabled. See ABCD-ON ABCD-ON Note. Fitting Keypads The set/unset LEDs Use M4 25mm countersunk screws in at ABCD-ON shows the setting... -
Page 16: Step 4. Fit And Connect Expanders
Installation Menvier300 Step 4. Fit and Connect Mains Cabling Note: To avoid mains interference, the Expanders mains cable must enter the control unit through its own cable entry hole ( 9 in Fig Both wired and radio expanders are 2) and must not be mixed with other supplied in the same plastic case. -
Page 17: Fully Supervised Loop Connections
Menvier300 Installation 100 Ohms Alarm contacts 2K2 EOL Zone 1 Tamper contacts Zone 0 Alarm contacts 2K2 EOL Tamper contacts Figure 21 FSL Zone Wiring – Control Unit Figure 22 shows the wiring connections for FSL zones on the expander. Note that the... -
Page 18: Step 7. Connect Wired Outputs
Installation Menvier300 If you wish to connect two or more Step 7. Connect Wired detectors to a FSL zone, Figure 23 shows Outputs the connections required. Typical external siren/strobe 12V + Tamper In Tamper Out Strobe +ve Strobe -ve Trigger -ve... -
Page 19: Auxiliary Tamper
For 4- wire CC zones use the alarm contacts only CC wiring Cooper Security does NOT and link the tamper contacts together with recommend that you use CC wiring for this a short length of wire. -
Page 20: Remote Loudspeakers (Optional)
Installation Menvier300 Factory default types. See the Menvier40/100/300 Engineering Guide for details on how to change the defaults. Figure 30 Plug-By Communicator Wiring Figure 29 Wiring –TR from External Note: Comms O/P4 will be active when the Sounder to a Zone on the Expander. -
Page 21: Step 9. Fit And Connect Battery
Menvier300 Installation Note: You will need to speak to the ARC in minimum rating of UL94V-2 in order to order to confirm that the communicator has comply with EN60950 (this standard applies worked correctly. because of the energy content of 17Ah batteries). - Page 22 Installation Menvier300 give an alarm tone. The heartbeat LED intend to use for the wired zones. on the control unit PCB (see fig 3 ) Note: This initial choice fixes the wiring starts flashing. The navigation keys on type for the control unit and any attached any attached keypad start flashing.
-
Page 23: Transferring To Another Keypad
Menvier300 Installation control unit assigns the next free Leaving the Installer Menu address to that expander. The expander If you wish to leave the Installer Menu at gives a double “beep” confirmation tone any time. and shows its assigned address on the two-digit LED display. -
Page 24: Important! Saving Changes
Installation Menvier300 Note: If you attempt to leave the Installer Notes: Menu when a detector/device tamper is 1. You will see this screen the first time you active then the keypad displays a fault enter the Installer menu on a new control... -
Page 25: Restoring Factory Defaults Only
Menvier300 Installation 3. Identify the Reset Codes pins on the 2. EITHER: Press to go back to the main PCB (see item 8 in Figure 3). Installer Menu without changing defaults. 4. Short the Reset Codes pins together using a screwdriver or jumper link. -
Page 26: Step 11. Commission The System
Program the System Program the system to suit user requirements. Page 23 is a summary of the Installer Menu on the Menvier300. Please see the Menvier40/100/300 Engineering Guide for a more detailed description. Note: make sure that you allocate keypads correctly to Wards. -
Page 27: Installer Menu
Menvier300 Installation Installer Menu Siren time Zone alarms Call Acknowledge 1 DETECTORS/ DEVICES Strobe on Set Zone tampers Detectors Strobe on Unset System tampers Call Mode Add/Del Detectors Part Set B Confirmation Messages Program Zones Name Confirmation Mode Phone Book... - Page 28 “BS8243”. Appears only when System Options – Confirmation - Confirmation Mode is “BS8243”. Appears only when Masking is ON. There are 10 Shunt Groups available on Menvier300. Appears here only in part setting systems. Appears only when communications module fitted.
-
Page 29: Maintenance
300 zone hybrid endstation Description with remote keypads. Check the condition of the control unit standby battery. Manufacturer Cooper Security Ltd. Environmental Class II. Check the cabling to the keypad(s) and Operating Tested -10 to +55°C. expander(s) for signs of damage or temperature wear. -
Page 30: Security
You can connect any EN50131-6 ratings combination of these devices to the bus. The Menvier300 provides space for two 2. The system can be used as EITHER a 17Ah batteries, giving a total of 34Ah Ward Based System OR a part setting charge. -
Page 31: Electromagnetic Compatibility
Max p-to-p ripple 0.5V Other voltage: If you wish to connect the Menvier300 Standby Battery: 12V, 17Ah sealed control unit to a PC using either the lead acid, 2 off (not Ethernet or the USB port then make sure supplied). -
Page 32: Compliance Statements
The Menvier300 is compliant with code (HUD function not EN50130-5 environmental class II. compatible with BS8243) 734rEUR-00/01 CC/FSL Door Contact The Menvier300 is suitable for use in Transmitter (white) systems designed to comply with PD 6662: 2010 at grade 3. 734rEUR-05/06 CC/FSL Door Contact... - Page 33 Menvier300 Technical Specification key-eng Engineering keypad. xcelr Radio PIR xcelrpt Pet tolerant radio PIR xcelw Wired PIR xcelwpt Pet tolerant wired PIR Page 29...
