End Station PCB

Figure 2 shows the controls and connectors available on
the end station PCB.
1
2
3
4
5
14V4
1. Aerials.
2. 20VAC Input (from transformer).
3. Battery input (12VDC).
4. Kick start pins.
5. Connector block.
6. Reset codes pins.
Figure 2. End Station Printed Circuit Board

Keypad Controls and Displays

Figure 3 shows the controls and displays available on the
keypad.
1
2
3
4
5
6
1. LCD display .
2. Programming keys.
3. Navigation keys
4. Alert LEDs
Figure 3. Controls and Displays
0V 12V 1 2 3 4 TR - LS +
AUX OUTPUTS
7. Holes for module support pillars.
8. RF receiver.
9. "Heartbeat" LED.
10. Connector pins for tamper switch.
11. Sockets for communicator (I-SD01).
A
B
C
D
5. Setting and unsetting keys.
6. Panic Alarm (PA) keys.
7. Number/text keys.
8. Set/Unset LEDs.
1
11
10
9
8
7
6
0V 12V A B 0V 0V 12V 12V
BUS AUX AUX
8
1 2 abc 3 def
7
4 ghi 5 jkl 6 mno
7 pqrs 8 tuv 9 wxyz
* 0 #
