Installation
Protect the unit from dust and drilling debris when drilling
the fixing holes.
1. Fixing holes.
2. Cable entries.
Figure 7. Fixing Holes and Cable Entries
2. Fit and Connect the Keypad
Siting the Keypad
Do site the keypad:
Within the area protected by the alarm system.
At a convenient height and location for the user.
Out of sight of potential intruders.
Do NOT site the keypad:
Next to electronic equipment, particularly computers,
photocopiers or other radio equipment, CAT 5 data
lines or industrial mains equipment.
Where the cable run from the end station will be longer
than 100m (see page 14 ).
Page 12
1
2
i-on16
1
1
1
2
