  • Page 1 Security System Installation and Programming Guide...
  • Page 2 Every effort has been made to ensure that the contents of this book are correct. However, neither the authors nor Cooper Security Limited accept any liability for loss or damage caused or alleged to be caused directly or indirectly by this book.

  • Page 3: Table Of Contents

    i-on16 Contents 1. Introduction ..............1 Overview ................. 1 End Station and Keypad ............. 2 Opening the End Station Case............2 End Station PCB ................3 Keypad Controls and Displays ............3 Opening the Keypad .................4 2. Technical Specification ...........5 Specification..............5 General ..................5 Security..................5 Radio .....................6 Communications ................6...
  • Page 4 i-on16 Leaving the Installer Menu..........28 Restoring the Access Codes (1 stage Reset) ...... 28 Restoring All Factory Default Programming ......29 Detectors/Devices ............30 Detectors ..................30 Edit Zones ..................31 External Siren ................34 Radio Keypad ................35 Outputs .................

  • Page 5: Introduction

    i-on16 1. Introduction Overview The i-on16 is the control unit for a wirefree alarm system intended for domestic and light commercial use. The control unit comprises an end station and separate keypad. The end station has an ABS plastic case which contains the radio transceiver, power supply and backup battery.

  • Page 6: End Station And Keypad

    Introduction i-on16 End Station and Keypad Opening the End Station Case WARNING: When connected to the mains with power applied mains voltages are present on the shrouded heads of the terminal screws of the mains connector (“7” in figure 1). To gain access to the interior of the end station undo the two screws at the top of the case.

  • Page 7: End Station Pcb

    i-on16 Introduction End Station PCB Figure 2 shows the controls and connectors available on the end station PCB. 14V4 0V 12V 1 4 TR - LS + 0V 12V 0V 0V 12V 12V OUTPUTS AUX AUX 1. Aerials. 7. Holes for module support pillars. 2.

  • Page 8: Opening The Keypad

    Introduction i-on16 Opening the Keypad To open the keypad first gently prise off the trim on the front and remove the two screws. Next, carefully lever the front of the keypad (containing the pcb and display) away from the keypad rear housing. Figure 4.

  • Page 9: Technical Specification

    2. Technical Specification Specification General Product name i-on16. Product Description 16 radio zone endstation with remote keypad. Manufacturer Cooper Security Ltd. Environmental Class II. Operating temperature Tested -10 to +55°C. Dimensions: End station 384 x 245 x 94, mm HxWxD. Keypad...

  • Page 10: Radio

    Technical Specification i-on16 Code blocking Blocked for 90s after four incorrect codes in series. Proximity tag differs 4,294,967,296 (2 Radio Radio Section Operating frequency 868.6625MHz Narrowband. EN 300 220-3. EN 300 330-2 Telefication Transmitter range The range of the transmitters compatible with this control unit depends on the environment in which they...

  • Page 11: Power Supply

    i-on16 Technical Specification Power Supply This product complies with the requirements of EN50131- 6 Type A power supply at Grade 2 and environmental class 2. Mains power supply 230VAC +10%/-15%, 170mA max, 50Hz. End station psu 13.7VDC, 1.5A max End station consumption 145mA.

  • Page 12: Fuses

    Technical Specification i-on16 Fuses The control unit has a 250mA mains fuse. Electrical Safety Conforms to EN60950-1. Compliance Statements This product is suitable for use in systems designed to comply with PD 6662: 2004 at grade 2x and environmental class II. This product complies with the requirements of 50131-3 at grade 2 and environmental class II.

  • Page 13: Compatible Equipment

    i-on16 Technical Specification Compatible Equipment 706rEUR-00 Two button PA/tilt switch transmitter 710rEUR-00 Two button PA 713rEUR-00 Pet tolerant PIR 714rEUR-00 PIR Transmitter (Small case) 720rEUR-00 Smoke Detector Transmitter 726rEUR-50 Long range hand held PA 726rEUR-60 Short range hand held PA 734rEUR-00/01 CC/FSL Door Contact Transmitter (white) 734rEUR-05/06...

  • Page 14: Installation

    To do this you should conduct signal strength tests. Cooper Security produce the Scantronic 790r hand held signal strength meter for this purpose. Alternatively, you can power the control unit from a battery and use its...

  • Page 15: Fit The Control Unit Box

    PCB, take the standard precautions against damage by static electricity. Fitting Cooper Security recommend that you use at least four fixing holes when mounting the back of the end station on a wall. Use an No10/M5 countersunk screw at least 36mm long.

  • Page 16: Fit And Connect The Keypad

    Installation i-on16 Protect the unit from dust and drilling debris when drilling the fixing holes. 1. Fixing holes. 2. Cable entries. Figure 7. Fixing Holes and Cable Entries 2. Fit and Connect the Keypad Siting the Keypad Do site the keypad: Within the area protected by the alarm system.

  • Page 17: Fitting

    i-on16 Installation Note: Do not site two or more keypads closer than one metre together, otherwise their prox readers will interfere and be unable to read tags. Fitting Use M5 25mm countersunk screws in at least three fixing holes when mounting the back of the keypad on the wall. Figure 8.

  • Page 18: Keypad Addressing

    Installation i-on16 Cable Segregation Segregate the keypad cabling from any other wiring, such as mains supply cables, telephone cables, computer network cables and R.F. cables. Use cable ties to keep cables separated. Keep the keypad cable clear of cables supplying sounders or extension loudspeakers.

  • Page 19: Backlight Control

    i-on16 Installation MENU MENU 2 abc 3 def 2 abc 3 def 4 ghi 5 jkl 6 mno 4 ghi 5 jkl 6 mno 7 pqrs 8 tuv 9 wxyz 7 pqrs 8 tuv 9 wxyz Figure 10. Keypad Addressing Jumpers Backlight Control You can control the appearance of the keypad backlights and set/unset LEDs by fitting links over the appropriate...

  • Page 20: Tone Volume

    Installation i-on16 Tone Volume To adjust the volume of tones from the keypad: Louder Note: This control changes the volume of non-alarm tones (for example Exit/Entry tone). The volume of alarm tones is fixed. Softer Figure 11. Adjusting Tones and Chime Volume. 3.

  • Page 21: Mains Connection

    i-on16 Installation If you wish run mains cable through the side of the case, make sure that they are horizontal for the last metre before entering the case. Mains Connection Figure 13 shows the mains connection. Connect to a suitable supply using a double pole disconnect device in accordance with EN60950-1.

  • Page 22: Remote Loudspeaker (Optional)

    Figure 14 shows an example of using the wired outputs to drive an indicator LED. Fit and connect the I-RC01 (Optional) Cooper Security Ltd provide the I-RC01 relay card for use when connecting the outputs to devices that require voltage free contacts on their inputs. The I-RC01 is supplied with a short wiring loom that provides connections to each relay trigger input (see Figure 15).
  • Page 23 i-on16 Installation single wire allows you to connect the module to the 12V +ve aux supply in order to provide power for all four relays. The terminals on the edge of the card provide connections to the Normally Open, Common and Normally Closed terminals of the relays.

  • Page 24: Fit And Connect I-Sd01 (Optional)

    Installation i-on16 5. Fit and Connect I-SD01 (Optional) Safety Notice Figure 17 identifies connectors for Safety Extra-Low Voltage (SELV) and Telecommunications Network Voltage (TNV) circuits on the control unit's main PCB. These terms are used in accordance with the definitions in Safety Standard EN60 950.
  • Page 25 i-on16 Installation ADSL01 Figure 18. Fitting ADSL01 to I-SD01 Note: If the telephone line is NOT shared with an ADSL modem then leave the factory fitted jumpers in place. Fit the I-SD01 to the plug on module sockets (see 11 on Figure 2 ).

  • Page 26: Removing An I-Sd01

    Installation i-on16 PSTN See Note WARNING: Telecommunications Network Voltage A, B Connect to PSTN A1, B1 Connect to local phone extension (if required) For added surge protection connect to a suitable protective earth. Note: (UK only) connect to ringing wire from PSTN and to ringing wire on extension phone, if fitted.

  • Page 27: Fit And Connect Battery

    i-on16 Installation 6. Fit and Connect Battery Fit a 7Ah Lead Acid battery into the battery compartment in the bottom of the control unit, see Figure 21. Figure 21. Fitting the Battery Make sure that you secure the battery to the case with the strap provided.
  • Page 28 Installation i-on16 1. Apply mains power to the control unit. The keypads and internal sounder give an alarm tone. The heartbeat LED (see fig 2 ) starts flashing. The display initially shows: Language? English 2. Press u or n to show other Language? languages on the bottom line of Nederlands...

  • Page 29: Commission The System

    i-on16 Installation Note that the alert LEDs round the navigation glow red. This is because the end station lid is off and the tamper is active. 7. Remove both battery and mains power. Re-apply battery power followed by mains. The sounders stop. At this point you can carry on to commission the system.
  • Page 30 Installation i-on16 Figure 22. Close the Control Unit 7. Leave the Installer Menu. At this point the LED around the navigation keys will still show red. This is because the system is still waiting for you to acknowledge the tamper alarm caused when you applied power for the first time.

  • Page 31: Programming

    i-on16 Programming 4. Programming Entering the Installer Menu 1. Make sure the system is unset i-on16 and showing the standby screen 12:00 02/01/2008 (time and date). 2. Key in the Installer access code. When delivered from the factory the default Installer access code is “7890”.

  • Page 32: Leaving The Installer Menu

    Programming i-on16 in a total of ten incorrect codes (13 consecutive digits) then the system locks you out for 90 seconds. Leaving the Installer Menu If you wish to leave the Installer Menu at any time. 1. Press until the display shows Leave the words “Leave installer installer mode ?

  • Page 33: Restoring All Factory Default Programming

    i-on16 Programming The control unit loads the factory default access codes: User 1: 1234, Installer: 7890. After a short pause the keypad display shows the time and date. The red LEDs glow to show an alert that the panel lid is open. The system may start a tamper alarm.

  • Page 34: Detectors/Devices

    Programming i-on16 Detectors/Devices Detectors Add/Delete Detectors To use a radio zone the control unit must learn the identity of the radio detector. To learn radio detectors select Detectors-Add/Del Detectors. 1. Use the u or n keys to highlight a free zone and press >.

  • Page 35: Edit Zones

    i-on16 Programming You have the choice of deleting the detector ID or of defaulting the zone. Press u or n to see each of these choices. If you select “Delete Detector ID” then the control unit “forgets” the ID of the detector, but leaves any zone programming in place.
  • Page 36 Programming i-on16 Note: If you wish to leave the name unchanged then press . The display leaves the name change screen and restores the name of the zone to its previous value. Press when you have finished entering text. 2 abc 3 def A B C Æ...
  • Page 37 i-on16 Programming Final Exit. Zones of this type must be the last detector to be activated on exit, or the first to be activated on entry. You can use zones of this type to finally set the system, or to start the entry procedure. See page 39 to set the exit mode type.

  • Page 38: Zone Attributes

    Programming i-on16 Zone Attributes The attributes available are: Chime When enabled by the user, the system gives a non- alarm warning tone when any zones programmed as ‘Chime’ are opened. This facility operates only while the system is unset. Part Set When a user presses button B (part set), the control unit sets only those zones where the Part Set attribute = “Yes”.

  • Page 39: Radio Keypad

    i-on16 Programming The display shows a message asking you to operate the siren’s tamper. 3. Operate the siren’s tamper. The control unit learns the siren’s identity and gives a double beep. Deleting an External Siren To remove an external siren from the system: 1.

  • Page 40: Outputs

    Programming i-on16 Adding a Radio Keypad To make the control unit learn the Radio Keypad’s identity. 1. Select Detectors/Devices – Radio Keypad – ADD/DEL Radio Keypad. The display shows a list of available Radio Keypads from Radio Keypad 1 to Radio Keypad 2. Each line is a “memory slot”...
  • Page 41 i-on16 Programming Edit Outputs, and then select the output you wish to program. Changing Output Names When changing the output name, key in the letters from the keypad. Each number is associated with a range of letters in the same way as on many mobile phones. Figure 23 shows which letters appear on each key.

  • Page 42: Setting Options

    Programming i-on16 Strobe and Set This output is active for 10 seconds after the system has set. The output can be used to operate the strobe to give a visual indication that the system has completed setting. This output type also operates when the system is in alarm, and remains active until the user disarms the system.

  • Page 43: Part Set B Name

    i-on16 Programming Part Set B Name Use this option to give the Part set mode a name. The control unit displays this name to the user during setting. Exit Mode This option controls the exit mode for Full set. (For Part Set exit modes see page 40 .) The exit modes available to both Full Set and Part Set are: Timed Set.

  • Page 44: Entry Time

    Programming i-on16 them). The exit time can take any value between 10s and 120s. Entry Time This option controls the Entry Time for both Full and Part Set. The time can take any value between 10s and 120s. Part Set Exit Mode You can select an exit mode for part set that is different from that used during full setting.

  • Page 45: Strobe On Set

    i-on16 Programming Strobe on Set When set to ON this option causes the control unit to activate the strobe on any siren to give three flashes after the system sets. Strobe on Unset When set to ON this option causes the control unit to flash the strobe three times on any siren after the system is unset.

  • Page 46: Profiles

    However, selecting Factory Defaults does not erase the log. Installer Code The default Installer access code is 7890. Cooper Security Ltd recommend that you change this code to some other number. To change the Installer access code select System Options-Installer Code.

  • Page 47: Installer Text

    i-on16 Programming The Installer code allows you to enter the Installer Menu, and carry out an Installer reset. However, the Installer code does not allow you to set or unset the system. Installer Text If required the installer can key in a text message that appears on the first line of the display in the standby screen.

  • Page 48: Siren Time

    Programming i-on16 Siren Time To change the length of time that the system operates the siren during an alarm select System Options-Siren Time. Note: The durations offered by the display apply to a siren wired directly to the control unit. The 760ES radio siren has one of three fixed sounder durations in an alarm: 5seconds, 3mins or 15mins.

  • Page 49: Silence Alerts

    i-on16 Programming There are three options available: The remote control user cannot force set the system, even if you have applied the force set zone attribute to any zones. Confirm The remote control user can force set the system. They must operate as follows: 1) the user presses the appropriate button to set the system, 2) the control unit does not start setting, 3) the user presses the same remote control button to confirm that they wish...

  • Page 50: Alarms (Arc Reporting)

    Programming i-on16 Speech Dialler Deals with recording speech messages, selecting the alarm types that will trigger them, and selecting destinations for the messages. Line Fail Reporting Allows you to select how the control unit reports a communications failure if either the PSTN or the I- SD01 fails.

  • Page 51: Account Number

    i-on16 Programming control unit ends the call and then re-attempts to connect up to a maximum of 15 times. Alternate. The control unit reports to one of the two telephone numbers in the Phone Book. Operation: The control unit dials the first telephone number and attempts to connect to the ARC.
  • Page 52 Programming i-on16 Note: If you need to add a letter to the account code press the numbers keys repeatedly until the letter you want appears on the display. See page 32. Report Type To choose the report type to send to the ARC select: Reporting –...
  • Page 53 i-on16 Programming CID Reports CID reports are called ‘Telegrams’. Each telegram contains the site identification number (normally six digits long) and relevant event information. To make programming easier, the i-on16 groups CID telegrams together into Report Groups. Table 1 lists the telegrams included in each report group, and the relevant CID codes.
  • Page 54 Programming i-on16 Reset System reset Exit timeout Exit timeout and restore Omit Zone omit RF supervision Zone supervision fail and restore Radio keypad supervision fail and restore External siren supervision, fail and restore RF jamming Jamming fail and restore RF battery psu Smoke power supply unit fail and restore Zone low battery fail and restore Ext Siren low battery fail and restore...
  • Page 55 i-on16 Programming Enabled The system rearms Channel 3 once the siren timer has expired. Once the Channel is rearmed, the system is ready to report any new alarm. The system bypasses any detectors that are still violated. Notes: If a Final Exit Zone is triggered, Channel 3 becomes active at the end of the Programmed Entry time.

  • Page 56: Speech Dialler

    Programming i-on16 should take place. Next, key in the hour of the day (01 to 24) on which the test call should occur.. To make test calls on one day every month select Reporting – Alarms – Static Test Call – Monthly. From the display select a number between 1 and 31 to specify the day of the month on which the call should take place.
  • Page 57 i-on16 Programming Report Triggers Messages Destinations Phone Book Home message Dest 1 Y Message 1 Dest 2 N Dest 3 Y Dest 4 N None Fire Dest 1 N Message 2 Panic Dest 2 N Burg Dest 3 N Dest 4 N Technical Alarm Dest 1 = Tel No: 12345678 Dest 2 = Tel No: 87654321...
  • Page 58 Programming i-on16 display shows a progress bar indicating how long you have left to record. Press X to end recording. Press > to play back the message. Play Message Delete Message Press > to delete the message. When the display asks “Delete Message?” press Y. Use Lid Tamper This puts the control unit into a special mode where the tamper switch controls the recording and playback of the current message.
  • Page 59 i-on16 Programming The display then gives you a chance to key in a name for that number. The control unit will display this name in the phone book to help you remember what destination you wanted the message to go to. Press Y when you are happy that the name is correct.

  • Page 60: Line Fail Reporting

    Programming i-on16 Select a message from the list on the display. The control unit will show you a list of telephone numbers. If you gave a telephone number a name then the display shows the name instead of the digits of the number. Highlight a telephone number and press >...
  • Page 61 i-on16 Programming Disabled. The control unit does not monitor the telephone line. Audible. If the system is unset then the system logs the event. The control unit produces a short audible tone every minute. Entering a valid access code silences the sounders and the display indicates a telephone line fault.

  • Page 62: Testing

    i-on16 5. Testing If you think that part of the system is not working correctly then you can use the Test option to test various peripherals. The Test option also lets you check the identity of Remote controls, Panic Alarms and Tags. To start testing, make sure the system is idle then: 1.
  • Page 63 i-on16 Testing Radio Keypad Signals The display shows a list of the received signal strengths from each radio keypad. Outputs The display shows a list of the outputs programmed on the system. Select the output you wish to test. Press Y to finish the test.

  • Page 64: View Log

    Testing i-on16 View Log The control unit keeps a log of the last 250 events (for example, alarms and setting/unsetting). You can read the log when the system is completely unset. 1. Enter the Installer Menu and select View Log. The display shows you the most recent log event.

  • Page 65: Maintenance

    i-on16 6. Maintenance The control unit should be inspected once per year. At each inspection: Check the control unit for obvious signs of damage to the case or its lid. Check the action of the back tamper. Check the condition of the control unit standby battery. Check the cabling to the keypad(s) for signs of damage or wear.

  • Page 66: Appendix - Profile

    i-on16 Appendix - Profile On initial power-up, or after defaulting the system, the control unit offers you the choice of loading a profile. The profile supplies the following values in the Installer Menu. If you do not select the profile then the control unit makes all zones “not used”...
  • Page 67 i-on16 Appendix REPORTING (if I-SD01 fitted) Speech dialler Alarms Call mode Enabled Call mode Disabled Call acknowledge Disabled Report Type Fast Format Report triggers FF Channels Message 1 Ch 1 Fire Event 1 Burg Ch 2 Panic Event 2 Ch 3 Burg Event 3 Ch 4...
  • Page 68 Appendix i-on16 www.coopersecurity.co.uk Product Support (UK) Tel: +44 (0) 870 757 5400. Available between: 08:15 and 17:00 Monday to Friday. Product Support Fax: (01594) 545401 Part Number 11847975 Issue 4 Page 64...
