  • Page 1 Security System Programming Reference...
  • Page 2 The contents of this book are subject to change without notice. Printed and published in the U.K. This manual applies to software used in the i-on40 control unit with version 2.02 software. Page ii...

  • Page 3: Table Of Contents

    Contents Introduction ...............1 About this Guide ............... 1 System Overview .............. 1 Part Setting or Partitioned System............1 Communications ................2 Entering and Leaving Installer Menu........3 Entering the Installer Menu..........3 Leaving the Installer Menu ..........4 Important! Saving Changes to the Installer Menu ....5 Restoring Access Codes............
  • Page 4 Mains Fail Delay ................59 Communications.............. 60 ARC Reporting................61 Speech Dialler ................68 SMS..................... 73 Line Fail Response ................. 75 Line Fail Delay................76 IP Network (Own) ................76 Downloading ................. 79 Testing ................84 Test................84 Sirens and Sounders ..............84 Wired Keypad................

  • Page 5: Introduction

    This guide contains a detailed description of programming an i-on40 system using the Installer Menu. To install, connect and start up an i-on40 control unit please read i- on40 Installation Guide. If you need to add or administer users (and their remote controls, PA buttons and prox tags) then you must enter the User Menu.

  • Page 6: Communications

    Introduction i-on40 Part Setting. In a Part Setting System the i-on40 can set in one of four ways: either Full set or three varieties of Part Set. In Full Set the control unit pays attention to all detectors. In each of the three Part Sets, the control unit ignores all detectors that do not have the appropriate Part Set attribute (see page 16 ).

  • Page 7: Entering And Leaving Installer Menu

    Entering and Leaving Installer Menu Entering the Installer Menu 1. Make sure the system is unset i-on40 12:00 23/07/2009 and showing the standby screen (time and date). 2. Key in the Installer access code. When delivered from the factory the default Installer access code is “7890”.

  • Page 8: Leaving The Installer Menu

    Entering and Leaving Installer Menu i-on40 appears on the bottom line. Press u or n to display the other sub-options. Note: 1. After you initially gain access to the Installer Menu, you may leave and re-enter using the Installer access code by itself for up to 30 minutes after you last exited the Installer Menu.

  • Page 9: Important! Saving Changes To The Installer Menu

    Entering and Leaving Installer Menu Press to return to the Installer Menu. You must rectify the fault (or delete the device from the system) before you can leave the Installer Menu. Important! Saving Changes to the Installer Menu When you make changes to the Installer Menu the control unit holds those changes in temporary memory until you leave the Installer Menu.

  • Page 10: Restoring Factory Defaults Only

    Entering and Leaving Installer Menu i-on40 6. Remove the short from the Reset pins. 7. Reconnect the battery. Close the control unit lid (to restore the tamper switch). Key in the Master User code 1234 to silence the sirens. Press Y twice (if necessary) to acknowledge any alerts.

  • Page 11: Installer Mode Programming

    Installer Menu on a keypad. Editing Text In the i-on40 zones, setting levels, partitions, keypads, outputs and users can all be named. Also, account numbers for Downloader can take letters as well as numbers.

  • Page 12: Detectors/Devices

    1 to 40. Wired detectors occupy zone numbers 1 to 16 and radio detectors occupy zones 17 to If you selected 4-Wire Closed Circuit then the i-on40 has a total of 32 zones. Wired detectors occupy zones 1 to 8, while radio detectors occupy zones 17 to 40.
  • Page 13 Installer Mode Programming 1. Use the u or n keys to highlight a free zone and press > or Y. The display shows an “*” next to zones where the control unit has already learned detectors. 2. Activate the detector’s tamper.
  • Page 14 Installer Mode Programming i-on40 1. Use the u or n keys to highlight a zone you wish to delete (the display shows an “*” next to zones that have detectors) and press >. 2. You have the choice of deleting the detector ID or of defaulting the zone.
  • Page 15 Installer Mode Programming 2. When you have found the zone you wish to edit press > or Y. The bottom line of the display shows “Name”. 3. Press u or n to see the Type, Attributes or Partition options for that zone. Press or Y to select the >...
  • Page 16 Installer Mode Programming i-on40 Reporting option (see page 61). PA alarms operate whether the system is set or unset. Fire Alarm (02). Smoke or heat detectors connected to Fire Alarm zones cause the sirens to give a pulsing fire signal.
  • Page 17 Installer Mode Programming full alarm. If a technical alarm zone is activated (and the control unit correctly programmed, see page 60 ) then the control unit starts communication and logs the event. If the technical alarm occurs while the system is set, then system makes no audible alarm.
  • Page 18 Installer Mode Programming i-on40 to set or unset the system. 2. When the user operates the keyswitch while the system is unset then the control unit starts the programmed exit mode. 3. When the user operates the keyswitch while the system is set then the control unit unsets the system immediately.
  • Page 19 Installer Mode Programming If the alarm system is set then the control unit logs the event, starts any programmed communication, but does not start an alarm. External PSU Low Volts (13). Use this zone type to monitor the Low Voltage output of an external power supply unit.
  • Page 20 Installer Mode Programming i-on40 2. Scroll through the list of partitions for that zone. Press the > or < keys to change the status of the zone. “Yes” means the zone is allocated to that partition. 3. Press Y to save your changes and return to the list of zones.
  • Page 21 Installer Mode Programming Alarm, Entry Route and Tamper zone types. During setting the keypad displays a brief message to inform the user that one or more zones are in soak test. Double Knock Zones programmed with this attribute will cause an...

  • Page 22: Wired Keypads

    Options – Force Set menu. See page 57.) Wired Keypads The i-on40 allows you to give each wired keypad a name, and assign a keypad to one or more partitions. The control unit displays the name you give to the keypad when it is reporting faults or other events, making it easier to locate the affected device.
  • Page 23 Installer Mode Programming Assigning keypads to Partitions The i-on40 allows you to assign keypads to any of the partitions. Once you have assigned a keypad to a partition then that keypad will display messages and give tones for the assigned partition(s).
  • Page 24 Installer Mode Programming i-on40 might part set partitions 1 and 2, but on keypad 2 it could be programmed to full set partition 3. In addition, each of the A, B, C or D keys can have a name. The keypad displays this name while the system is setting after the user presses that key.

  • Page 25: Radio Keypads

    The display asks you to activate the tamper switch on the Radio Keypad. 3. Activate the Radio Keypad tamper. The Radio Keypad signals its identity to the i-on40 control unit. When the control unit learns the Radio Keypad’s identity it gives a double beep.
  • Page 26 4. Key in the name of the radio keypad. For hints on editing names see page 7 . 4. Press Y to save the text. Assigning a Radio Keypad to Partitions The i-on40 allows you to assign radio keypads to one or more of the partitions: Page 22...

  • Page 27: External Sirens

    Installer Mode Programming 1. Select Detectors/Devices – Radio Keypad. The bottom line of the display shows the first in a list of “memory slots” for the radio keypads. If a memory slot is occupied by a radio keypad then the bottom line of the display shows a “*”...
  • Page 28 Installer Mode Programming i-on40 1. Select Detectors/Devices – External Siren – Add/Del Ext Siren. The display shows four possible “memory slots” for external sirens. A slot already allocated to a siren shows a “*” at the beginning of its line.

  • Page 29: Info Modules

    The 771r Info Module is an external display module that can show the setting state of the system or one or more partitions. You must teach the identity of the i-on40 control unit to each Info Module that you wish to use.
  • Page 30 Installer Mode Programming i-on40 5. Press Y on the i-on40 keypad to confirm that the Info Module has learned the identity of the i-on40. Disabling Info Modules If you physically remove the Info Modules from a system (for example, when a user no longer requires them) then you may wish to stop the control unit trying to update the Info Module’s display.

  • Page 31: Wams

    Mode 4 Sounder Module. The WAM operates as a radio link to allow you to remotely connect a standard wired siren to the i-on40 control unit. In this mode the WAM also provides inputs so that the wired siren can report back tampers, low battery or other trouble conditions.
  • Page 32 The display asks you to activate the tamper switch on the WAM. 3. Activate the WAM tamper. The WAM signals its identity to the i-on40 control unit. When the control unit learns the WAM’s identity the keypad gives a double beep.

  • Page 33: Outputs

    To use a radio output on a WAM see page 27 . To use a radio output on a 762r, 768r or 769r receiver you must teach the identity of the i-on40 control unit to the receiver. Note: If you are teaching 762r, 768r, or 769r receivers then make sure that you disable IR learn on the receivers first.
  • Page 34 Installer Mode Programming i-on40 1. Select Outputs – Radio Outputs – Add Outputs. The bottom line of the display shows the first in the list of eight available radio outputs. 2. Press u or n to select the radio output that you wish to make the receiver learn and press Y.

  • Page 35: Wired Outputs

    Installer Mode Programming 3. Press > to give the output a name. See page 7 for hints on editing names. Press Y when you have finished editing the name. To give a radio output a type: 1. Select Outputs – Radio Outputs – Edit Outputs.
  • Page 36 Installer Mode Programming i-on40 The i-on40 also lets you change the polarity of the wired output, to suit the type of equipment that the output must work with. To give a wired output a name: 1. Select Outputs – Wired Outputs.

  • Page 37: Plug-By Outputs

    4. Press > or < to change the polarity. 5. Press Y to store any changes to the polarity. Plug-By Outputs The plug-by outputs are designed for use by standalone communicators (see i-on40 Installation Guide for connection details). You can give each output a name, a Page 33...

  • Page 38: Output Types

    Installer Mode Programming i-on40 type, and change its polarity. Programming plug-by outputs is the same as programming wired outputs, but you must use the Outputs – Plug-by Outputs menu. Note: The activity of the plug-by outputs is affected by the alarm response you select. For example, if you select the alarm response “Siren”...
  • Page 39 Installer Mode Programming Type: Active when: Assign to Partitions? Open/Close The system is unset. (04) Inactive when the system is set. Alarm Abort An alarm in the selected (05) partition has been aborted by the user within the 90s abort period.
  • Page 40 Installer Mode Programming i-on40 Type: Active when: Assign to Partitions? Panel A/C Fail Either Mains power is (12) absent for between 52 and 59 minutes, OR a zone of type “External PSU A/C Fail” has been triggered. The control unit deactivates...
  • Page 41 Installer Mode Programming Type: Active when: Assign to Partitions? Panel Battery The control unit detects a Fault (13) fault with its backup battery, OR a zone of type “External PSU Battery Fault” has been triggered. If the alert was caused by an “External PSU Battery...
  • Page 42 Installer Mode Programming i-on40 Type: Active when: Assign to Partitions? External PSU An external power supply Fault (15) fault signal triggers a Power output fault zone. The control unit deactivates the output when the zone has been restored and a...
  • Page 43 Installer Mode Programming Type: Active when: Assign to Partitions? ATS Test (20) (This output type appears only for Plug-by outputs.) The line fault input signal goes to 12V. The operation of the Line Fault input and the ATS test output...
  • Page 44 Installer Mode Programming i-on40 Type: Active when: Assign to Partitions? Entry Exit The entry or exit time Follow (23) starts and deactivates at the end of the entry/exit time, or if the entry/exit time is terminated. The output can be used for a separate entry/exit buzzer.
  • Page 45 Installer Mode Programming Type: Active when: Assign to Partitions? Smoke Sensor This output is active (0V) Reset (28) all the time except when a user acknowledges a fire alarm: after which the control unit deactivates the output for three seconds.
  • Page 46 Installer Mode Programming i-on40 Type: Active when: Assign to Partitions? Part Set D Setting Part Set D. (37) Deactivated on unsetting Part Set D. (Available only in a Part Setting system) Set Fail (38) A set command fails. Remains active until the user acknowledges the set fail.

  • Page 47: Setting Options" And "Partitions" Menus

    Part Setting or Partitioned System? When you first power-up a new i-on40 (see i-on40 Installation Guide ), or if you restore an i-on40 control unit to factory defaults (see page 53 ), you must choose between having a Part Setting system or a Partitioned system.

  • Page 48: Options

    Installer Mode Programming i-on40 menus, the table shows the page number where the description of each option can be found. 3 SETTING OPTIONS PAGE 3 PARTITIONS PAGE Full Set Partition 1...4 Name Name Exit mode Exit Mode Settle time (see note 1)
  • Page 49 Installer Mode Programming Partition a name. The control unit displays this name to the user during setting. Exit Mode The exit modes available are: Timed Set Use this option to make the system set after a delay. Use the Exit Time menu (see page 46) to choose the delay.
  • Page 50 Installer Mode Programming i-on40 menu but does not give any exit tones. When the system sets the keypad gives a double beep confirmation tone. The keypad(s) give a double beep confirmation tone at the end of all setting modes. Settle Time This option allows you to define a time delay to allow detectors to settle before the system sets.
  • Page 51 Installer Mode Programming activate any output programmed as Strobe, plus the strobe on any 760ES wireless siren. The outputs/strobes are active for three seconds after the system unsets. Strobe On Unset applies to Full Set and all the Part Sets.

  • Page 52: Full Set Link

    Installer Mode Programming i-on40 Routes during part set. In a Partitioned system, all Entry Route zones, belonging to the partition, with the Part Set attribute will continue to act as Entry Routes during part set. Final Exit In a Part Setting System, any Entry...

  • Page 53: User Access

    If you select any of the FSL options then the control unit provides 16 wired zones, numbered zone 01 to zone 16. See i-on40 Installation Guide for wiring details. User Access To give users access to various system facilities select System Options –...

  • Page 54: User Reset

    Installer Mode Programming i-on40 Quick Omit This option allows users to omit a zone that is active (has it’s alarm contacts open) while they are setting the system. The zone must have the Omittable attribute (see page 16). By pressing Y the user can set the system if there are zones with the Omit Allowed attribute active.

  • Page 55: Dd243 (Uk Only)

    Installer Mode Programming System Tampers The user can reset the system after an alarm caused by a system tamper, for example the control unit lid opening, or a keypad being opened. The installer must reset the system after a system tamper alarm.
  • Page 56 Installer Mode Programming i-on40 Entry Keypad Lock This option determines whether the user can unset the system by entering an access code after opening the entry door. Off: The user can enter an access code at the keypad after the entry door opens (used for DD243:2004 clause 6.4.4).

  • Page 57: Profiles

    However, selecting Factory Defaults does not erase the log, or delete any users Installer Name This field controls the user name employed by the login screen of the i-on40 Web Server. When logging in to the Page 53...

  • Page 58: Installer Code

    Installer reset. However, the Installer code does not allow you to set or unset the system. When logging into the i-on40 Web Server you must key into the password field the same code as you have programmed into the Installer Code field.

  • Page 59: Auto Rearm

    Installer Mode Programming enabled, or the communications outputs wired to an appropriate communicator and correctly programmed). This option controls the associated audible alarm. Audible As well as starting communications the control unit starts PA alarm tones from the keypads and loudspeakers, and activates any siren outputs.

  • Page 60: Siren Time

    Installer Mode Programming i-on40 programmed Siren Delay before operating the siren. The system then operates the siren for the programmed Siren Time. Note: Siren Delay has no effect if the Alarm Response Mode does not require communications or if a line fault is detected.

  • Page 61: Jamming

    Installer Mode Programming If a wirefree detector loses contact for more than two hours then the control unit raises an alarm. The options available for this alarm are: Option: With system SET, With system UNSET the control unit: the control unit: Disabled Does nothing.

  • Page 62: Tamper Omit

    Installer Mode Programming i-on40 The user need only press the remote control button once to complete setting the system. Note: The Confirm and On options will also allow a user with a remote control to set the system if a reset is required after an alarm.

  • Page 63: Silence Alerts

    Installer Mode Programming code. This acts as a seed for computing both the reset code and its anti-code. The ARC usually generates the CSID code. To install the CSID code: 1. Call the ARC and obtain the CSID code.

  • Page 64: Communications

    Installer Mode Programming i-on40 The values available are 0 to 10 minutes. Note that when the value is set to 0 minutes, mains interruptions of less than 9 seconds will not start an alert. Communications Note: If you have connected a plug-by communicator then use the Outputs - Plug-by Outputs menu to program the communicator.

  • Page 65: Arc Reporting

    Installer Mode Programming Downloading Deals with setting up phone numbers, account numbers for the downloader, and controlling the type of connection you wish to allow. Note: Apart from Downloading and IP Network (Own), the above menu items appear only if the appropriate module is fitted.
  • Page 66 Installer Mode Programming i-on40 control unit ends the call and then re-attempts to connect up to a maximum of 15 times. Alternate. The control unit reports to one of the two telephone numbers in the Phone Book. Operation: The control unit dials the first telephone number and attempts to connect to the ARC.
  • Page 67 Installer Mode Programming 1. You understand basic IP terminology. 2. You have obtained the necessary information from your Internet Service Provider. Unit Name Use this option to store a unique name for the unit. Polling IP Address Key in the IP address of the remote polling engine. If the ARC is not using a polling engine then leave this option blank.
  • Page 68 Installer Mode Programming i-on40 If you selected Fast Format in Report Type then you can select Communications - ARC Reporting - Fast Format Channels to allocate one of the following events to each of eight channels (defaults in brackets): Not used...
  • Page 69 SIA versions in Communications - Report Types. See Appendix II for a description of the CID and SIA formats.) To make programming easier, the i-on40 groups CID/SIA telegrams together into Report Groups. Table 3 lists the telegrams included in each report group, and the relevant CID/SIA codes.
  • Page 70 Installer Mode Programming i-on40 Omit Zone omit RF Supervision Zone supervision fail and restore Radio keypad supervision fail and restore External siren supervision, fail and restore* RF Jamming Jamming fail and restore* RF Battery/PSU Smoke power supply unit fail and...
  • Page 71 Installer Mode Programming Burg Comms Rearm (This menu appears only if you select “Fast Format” in Communications - Report Type.) This menu option determines what the control unit does with the “Burg” Fast Format channel 3 at the end of the siren run time.

  • Page 72: Speech Dialler

    Installer Mode Programming i-on40 Dynamic Test Call In dynamic testing the system makes a test call 24 hours after the last alarm communication. To enable dynamic testing select Communications – ARC Reporting – Dynamic Test Call – Enabled. Static Test Call...
  • Page 73 Installer Mode Programming microphone and replay them to a pre-programmed telephone number to report an alarm. One message is called the “Home message”, and is always played at the beginning of a report. You should use this message to identify the control unit and it’s location.
  • Page 74 Installer Mode Programming i-on40 control unit (usually by pressing buttons on the telephone key pad). The commands available are: Function End this call DTMF ‘5’ Play ‘Home’ and ‘alarm’ message DTMF ‘3’ Clear down DTMF ‘9’ Note that when the called party answers a speech dialler call there could be a six second delay before the control unit starts playing the home message.
  • Page 75 Installer Mode Programming 1. Start with the control unit lid off and the tamper switch open. 2. At the keypad select Use Lid Tamper and press Y. 3. At the control unit hold down the tamper switch. When the red LED on the I-SD02 glows recite your message.
  • Page 76 Triggers In the i-on40 you can link up to five different trigger events to each speech message. A trigger event is one item selected from a list of alarm types.

  • Page 77: Sms

    Installer Mode Programming Note: There are a total of five voice messages available. The control unit always sends the Home Message at the beginning of every speech report. The control unit then sends messages 1, 2, 3 or 4 to the telephone numbers you selected.
  • Page 78 Installer Mode Programming i-on40 The control unit sends the text in the Home Message to every telephone number you have programmed for SMS messages. The control unit also sends message 1 to telephone number 1, message 2 to telephone number 2, message 3 to telephone number 3 and message 4 to telephone number 4.

  • Page 79: Line Fail Response

    Installer Mode Programming The Home Message provides space for 12 characters. Use the this text to identify the control unit. Each numbered message provides space for 30 characters. Key in a message that relates to the type of alarm event you select as a trigger (See “Triggers”...

  • Page 80: Line Fail Delay

    The control unit cancels any programmed siren delay if the line is out of order when an alarm occurs. Note: Cooper Security recommend audible response for line fault. Silent. If the system is unset then the display indicates a telephone line fault and the control unit logs the event.
  • Page 81 Gateway Address This is the IP address of the router that connects the local network, to which the i-on40 is connected, to rest of the Internet (or to a larger network).If necessary, key in the gateway IP address. This number has the same format as the IP address.
  • Page 82 DHCP (Dynamic Host Control Protocol) to obtain these values from a DHCP server. Gateway Address This is the IP address of the router that connects the local network, to which the i-on40 is connected, to Page 78...

  • Page 83: Downloading

    Installer Mode Programming rest of the Internet (or to a larger network).If necessary, key in the gateway IP address. Downloading The control unit can communicate with Downloader software running on a PC. Downloader connects with the control unit either locally over the USB (Universal Serial Bus) port or, if you have fitted a communications module, remotely over a telephone line.
  • Page 84 Installer Mode Programming i-on40 Local Connect the control unit to a PC (for example a laptop) using a local USB cable. Note: The control unit will leave the Connection Type menu if Downloader does not make a call within 30 minutes.
  • Page 85 Installer Mode Programming Once Downloader is connected to the control unit then it has access to all system programming. If you wish to provide secure access then use either Call Out Only or Secure Callback. Please note that you cannot use Secure Callback with Local connection.
  • Page 86 Installer Mode Programming i-on40 Phone Book (This option appears only when the i-sd02, i-dig02 or i- gsm02 module is fitted.) Select Downloading - Phone Book to program two separate, 31-digit telephone numbers that the system will use during downloading. When the remote PC operator makes...
  • Page 87 Installer Mode Programming Secure Callback (This option appears only when the i-sd02 or i-gsm02 module is fitted.) Select Downloading - Secure Callback to allow Downloader to use a third callback number (independent of the telephone numbers in the Downloading – Phone Book option).

  • Page 88: Testing

    Testing The i-on40 provides three options within the Installer Menu to help in testing: the Test option itself, the View Log option to see what events have been recorded, and the About option so that you can check on the release level of the software.
  • Page 89 Testing should be silent. Note that both siren and strobe should operate. Wired Sirens This option allows you to operate all outputs programmed as “Siren” and “Strobe”. Press > to turn the outputs on. Press > again to turn the outputs off.

  • Page 90: Wired Keypad

    Testing i-on40 Wired Keypad Use this menu option to test the keypad you are currently holding (you cannot test a keypad remotely). When you start the test all four LEDs should glow. The LEDs around the navigation should should all glow red; every time you press a navigation key the LEDs change colour.

  • Page 91: Signal Strengths

    Testing Signal Strengths This option allows you check the received signal strength from all the radio transmitters belonging to the system. The keypad display shows first: the strength of the most recent signal it has received from a transmitter, and...

  • Page 92: Outputs

    Testing i-on40 WAM Signals The display shows a list of the received signal strengths from each learned WAM. Outputs This option has three sections: Radio Outputs, Wired Outputs and Plug-by Outputs. Press u or n followed by > to select the section you want to test.

  • Page 93: Prox Tags

    Testing 3. Press each button on the panic alarm in turn. Make sure the display reports each button correctly. 4. Press X to end the test. Prox Tags To test a proximity tag: 1. Select Test – Prox Tags from the Installer Menu.

  • Page 94: Psu Current

    Testing i-on40 2. Key in the digits of the telephone number you wish to call. 3. Press Y to start the test call. The keypad display shows the progress of the call: “Dialling” while the speech dialler is dialling the telephone number, followed by “Connecting”...

  • Page 95: About

    Testing 250 events. The entire log will store its records for at least 10 years without power. When you view the log, the display initially shows users by their number (for example User01). Pressing > displays any name programmed for the user.
  • Page 96 Testing i-on40 2. Press >. The bottom line of the display shows “IP Link Status”. 3. Press >. The bottom line of the display shows “OK” if the control unit has successfully connected to a PC by way of an Ethernet cable.
  • Page 97 Testing 12. Press X to leave the sub menu. To see IP Network information for the built-in Ethernet port: 1. Select About – Comms from the Installer Menu. The bottom line of the display shows the communications module type (or “None” if no module is fitted).
  • Page 98 Testing i-on40 10. Press >. The bottom line of the display shows the current gateway address. Note that this may be blank if you are connecting a PC/laptop directly to the control unit. 11. Press < then n. The bottom line of the display shows “MAC address”.

  • Page 99: Appendix I Installer Menu Defaults

    Appendix I Installer Menu Defaults Important: Where noted below the defaults listed enable the control unit to comply with EN50131 requirements. If you change these setting then the installation may no longer comply. If the control unit does not comply with EN50131 you must remove any labelling that indicates compliance.
  • Page 100 Appendix I i-on40 Part Set Alarm Response: Siren + FORCE SET: Comms (See Note 2) TAMPER OMIT: Part Set Final Exit: Final exit Disabled Part Set Entry Route: Entry Route (See Note 2) Strobe on Set: On CSID CODE Strobe on Unset: On...
  • Page 101 Appendix I Enabled Note: 1. DD243 is a UK requirement. If Static Test Call: this option is disabled in non-UK Disabled countries then the control unit (See Note 3) will still comply with EN51031. Burg Comms Rearm: 2. This setting is required in Disabled order to comply with EN50131.

  • Page 102: Appendix Ii: Arc Communication Formats

    Appendix II: ARC Communication Formats Note: To comply with EN50131 you must fit a communications module. Fast Format Fast Format is the format most widely used in the UK. When using the Fast Format, each message transmitted to the ARC consists of the following: A 4,5 or 6-digit account number.

  • Page 103: Sia 1, Sia 2, Sia 3 And Extended Sia 3

    Appendix II 2 is the checksum value, which the ARC needs to verify to confirm a valid message has been received. Example 2 - 1234 18 3137 01 015 F The only difference between this and the first example, is the event qualifier of 3 to indicate a restore of a system tamper alarm, and the checksum value.
  • Page 104 Appendix II i-on40 For example, if there is a fire alarm on zone 2 of partition 4 at 10:15 (partition 4 account number is 10), the message would be: SIA1: #000010|NFA2 SIA2: #000010|N/ri4/FA2 SIA3: #000010|Nti10:15/ri4/FA2 #000010|AFire Zone 2 Extended SIA3: #000010|Nti10:15/ri4/FA2/AFire Zone 2...

  • Page 105: Appendix Iii: Programming A Common Area

    Appendix III: Programming a Common Area Some commercial premises include two or more separate areas linked by a common area. You can program the i- on40 to allow users to set each area independently, and then set the common area automatically when the last occupant leaves the premises.

  • Page 106: Installation And Programming

    In the i-on40 Partition 1 is always the common area. Use Partition 1 for the Foyer, Kitchen and Toilet. Partition 2 can be used for the Factory and Loading Bay.

  • Page 107: Partition And Other Programming

    Appendix III Partition and Other Programming Menu Sub Menu Option Add/delete Detectors/Devices External Radio Siren (if to be fitted) Wired keypads Keypad 01 Name = Office Partition 3 Keypad 2 Name = Factory Partition 2 Keypads 3 & 4 – not fitted...

  • Page 108: User Programming

    Appendix III i-on40 User Programming User Code Type Partitions 1234 Master User Whole system – P2 + P3 2222 Partition user P2 (Factory) 3333 Partition user P3 ( Office) User Operation To set: Full System User 01 enters code or Prox + (User 01 can select an individual Partition or full set the whole system.)

  • Page 109: Index

    Index 24 hour alarm Comms module ......61 output type......41 removing......61 zone type ......12 speech dialler......68 762r ........29 Communication 768r ........29 SIA........99 769r ........29 Communications......2 770r ........27 menu ........60 771r ........
  • Page 110 Index i-on40 Exit time polling (for arc) ..... 63 Part setting......46 web server ......77 External PSU IP Network ....... 60 AC Fail zone type....14 ARC reporting ....... 62 battery fault zone type ... 14 downloading ......82 fault output type ....
  • Page 111 Index Output Polling IP address ...... 63 Digi On Board output....98 Profile........53 Outputs Proximity tag plug-by ........ 33 for entry code lockout .... 52 radio........29 testing ......... 89 Radio-learning....... 29 Quick set keys radio-name......30 enable ......... 49 radio-partitions .....
  • Page 112 Index i-on40 Silent PA ........54 downloading ......82 Silent set SMS ........75 Part setting......45 Speech dialler ....... 71 Single reporting ......61 Test call Siren ........39 dynamic ....... 68 confirmed/unconfirmed ..52 static ........68 delay ........55 Testing ........
  • Page 113 This page is intentionally blank. Page 109...
  • Page 114 This page is intentionally blank. Page 110...
  • Page 115 This page is intentionally blank. Page 111...
  • Page 116 Product Support (UK) Tel: +44 (0) 1594 541979 Available between: 08:15 to 12:30 and 13:00 to 17:00 Monday to Friday. Product Support Fax: (01594) 545401 Part Number 12003625 Page 112...
